14 | English
 Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
 Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
 Maintain power tools. Check for misalignment or bind-
ing of moving parts, breakage of parts and any other
condition that may affect the power tool's operation. If
damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power
tools.
 Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
 Use the power tool, accessories and tool bits etc. in ac-
cordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
Service
 Have your power tool serviced by a qualified repair per-
son using only identical replacement parts. This will en-
sure that the safety of the power tool is maintained.
Safety Warnings for Drills
 Wear ear protectors when impact drilling. Exposure to
noise can cause hearing loss.
 Use auxiliary handle(s), if supplied with the tool. Loss
of control can cause personal injury.
 Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord. Cutting ac-
cessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an
electric shock.
 Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance. Contact with electric lines can lead to fire
and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.
 Hold the machine with a firm grip. High reaction torque
can briefly occur while driving in and loosening screws.
 When working with the machine, always hold it firmly
with both hands and provide for a secure stance. The
power tool is guided more secure with both hands.
 Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
 Always wait until the machine has come to a complete
stop before placing it down. The tool insert can jam and
lead to loss of control over the power tool.
1 609 92A 0NJ | (6.6.14)
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.
Products sold in AUS and NZ only: Use a residual current de-
vice (RCD) with a rated residual current of 30 mA or less.
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal and plastic. Ma-
chines with electronic control and right/left rotation are also
suitable for screwdriving and thread-cutting.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Keyless chuck
2 Gear selector
3 "Drilling/Impact Drilling" selector switch
4 Rotational direction switch
5 Handle (insulated gripping surface)
6 Lock-on button for On/Off switch
7 Thumbwheel for speed preselection
8 On/Off switch
9 Release button of the dust extraction
10 Dust box, complete (Microfilter System)
11 Auxiliary handle (insulated gripping surface)*
12 Button for adjustment of the telescopic guide
13 Dust extraction
14 Telescopic guide
15 Button for depth stop adjustment
16 Dust collector for drill bit
17 Depth stop*
18 Screwdriver bit*
19 Universal bit holder*
20 Chuck key*
21 Key type drill chuck*
22 Hex key **
