Ravaglioli RAV4300 Traduction Des Instructions Originales page 32

RISERVATO AL PERSONALE AUTORIZZATO ALL'INSTALLAZIONE - ONLY FOR INSTALLATION-AUTHORIZED STAFF
MODELLO
MODEL
RAV4300
RAV4350
RAV4351
RAV4400
RAV4401
RAV4405E
RAV4501E
RAV4650
RAV4800
32
F
N
M
A B C
4280 3770 4440 2755 2345 230 180 230 280 4360 2805
4430 3920 4594 2805 2395 230 180 230 280 4510 2855
4580 4070 4800 2955 2545 230 180 230 280 4660 3005
4980 4470 5245 3155 2745 230 180 230 280 5200 3205
4580 4070 4910 3155 2745 230 180 230 280 4660 3205
5220 4710 5452 3155 2745 230 180 230 280 5300 3205
5220 4710 5555 3355 2945 230 180 230 280 5300 3405
5330 4720 5730 3780 3250 280 240 290 330 5410 3830
6175 5565 6445 3780 3250 280 240 290 330 6255 3830
L
B
C
A
D E F G
Fig.6
0716-M001-0
F
I
N
L
QUOTE ESPRESSE IN MILLIMETRI
DIMENSIONS ARE IN MILLIMETERS
H I L M N O
40 150
40 150
40 150
40 160
40 150
40 160
40 160
40 200
40 200
