Technical Data; Environmental Protection - WAGNER CONTROL PRO 350 M Traduction Du Mode D'emploi Original

Control Pro 350 M
Description
Nozzle 619 (for thick materials, e.g. interior wall paints. For coating larger surfaces)
Gun extension (30 cm)
Oil (118 ml)
Further information about the WAGNER range of products for renovating is available under www.wagner-group.com
Pump type
Power source
Power consumption
Fusing
Protection class
Max. spray pressure
Max. delivery rate
Sound pressure level *
Sound pressure output *
Oscillation level *
Max. temperature of coating substance
Hose length
Max. hose length
Product dimensions
Weight
* Measured in accordance with EN 50580:2014
Information about the oscillation level
The specified oscillation level has been measured according to a standard test procedure and can be used to compare against electric tools.
The oscillation level is also for determining an initial assessment of the vibrational strain.
Attention! The vibration emission value can differ from the specified value when the electric tool is actually in use, depending on
how the electric tool is being used. It is necessary to specify safety measures to protect the operating personnel. These measures are
based on an estimated shutdown during the actual conditions of use (all parts of the operating cycle are taken into consideration
here, for example periods when the electric tool is switched off, and, when it is switched on but running without any load).

Environmental protection

The device and all accessories and packaging have to be re-used in an environmentally friendly manner. Do
not dispose of the appliance with household waste. Support environmental protection by taking the appliance
to a local collection point or obtain information from a specialist retailer.
Leftover paint and solvents may not be emptied into drains, the sewage system or disposed of as household rubbish. It has
to be disposed of separately as special waste. Please pay special attention to the instructions on the product packaging.
Important Note regarding Product Liability!
Due to an EC ordinance in effect since 01.01.1990, the manufacturer is liable for his product only if all parts originate from or were
approved by the manufacturer and the devices are assembled and operated correctly. The use of other accessories and spare parts
can partially or completely invalidate the liability.
Accessories (not included in the delivery)

Technical Data

Piston pump
230 V 50 Hz/ 240 V
~ ~
600 W
Only connect to sockets protected with an FI fuse (16 A)
I
11 MPa (110 bar)
1.5 l/min
83 dB (A) Uncertainty K= 3 db
97 dB (A) Uncertainty K= 3 db
< 2.5 m/s Uncertainty K= 1.5 m/s
2
40°C
15 m
30 m
approx. 78 (93.5) x 38.5 x 52 cm
approx. 13.0 kg
50 Hz
2
GB
Order No.
0517619
0517700
2319722
27
