Advanced Display
Progrma Menu
Avdvanced
Pump Congig.
A: pH-/Rx/pH+
Relay Congig.
Rx Pump
Temp.
Flow
Cal
Password
Press Esc to exit any menu and confirm the settings by pressing Enter.
Display
Progrma Menu
Exit
000013791
Avdvanced
25°C
Avdvanced
On
Avdvanced
Full
Avdvanced
****
Save
Use Enter to access the sub-menus:
 Pump config.
 Relay config
 Temp.
 Flow
 Cal.

Password
Press Enter to modify the pump
configuration:

Configuration A: The first pump on
the left carries out the pH- function,
the pump in the middle the Redox
function and the one on the right
carries out the pH+ function, (pH-
/Rx/pH+).

Configuration B: The first pump on
the left carries out the pH function,
the pump in the middle the Redox
function and the one on the right
carries out the Flocculant function,
(pH/Rx/Flocc).
Press Enter and the + and - keys to modify
the outlet relay setting according to the
Redox measurement (Rx pump) or
according to an alarm condition (Alarm).
Press Enter and the + and - keys to set the
compensation temperature from 1 to 100°C.
If a temperature probe is connected, the
menu item will not be displayed as the
system will compensate automatically with
the value read by the probe itself.
Press Enter and the + and - keys to set the
flow to OFF or ON. This item enables or
disables the Flow inlet (see. Paragraph
10.0).
Press Enter and the + and – keys to set the
calibration to OFF or enable it to ON (Full)
Press Enter to set the system access and
modification password.
Use the + key to modify the figure and the –
key to scroll to the next figure and confirm
with Enter
Press the + and – keys to choose Save or
NoSave, i.e. to save the settings or not and
press Enter to confirm.
