FPE 050E - FPE 200E
6. Control description
6.1
Control unit
The heating device is equipped with an adjustable
electronic controller with display, six keys and an LED.
The control unit is located on the top on the right. All
settings can be selected using the six keys on the user
interface.
6.2
Key functions
On/off
Switching the heating device on or off.
Automatic operation
Room temperature control with:
Weekly program,
Presence detection.
Manual operation
Room temperature control by specifying:
Comfort temperature,
Eco temperature (lower temperature),
Frost protection temperature.
Window monitoring
Interruption of heating operation when window is open.
Setting keys + and -
Navigation through the menu and changing the setting
values.
6.3
Display
Shows the current settings. The display lights up for
approx. 10 seconds (factory setting) when this key is
activated.
www.dimplex.de/en
Heating operation on display
During heating operation, the HEATING OPERATION
ON symbol appears. When the specified temperature
is reached, the symbol disappears.
Energy efficiency display
The ENERGY EFFICIENCY display informs the user of
the energy consumption depending on the set room
temperature.
-
Arrow on green: low energy consumption
-
Arrow on red: high energy consumption
7.
Possible operating modes
Window monitoring
The room heating device is equipped with a monitoring
function that detects whether unnecessary energy is
being consumed due to an open window. In this case,
heating operation is interrupted. This function is set as
active at the factory.
Presence detection
In automatic operation, the controller detects whether a
person is in the room. The set comfort temperature
remains active for as long as a person is detected. If the
room is not in use, the temperature is lowered gradually
to save energy:
By 1°C after 30 minutes, by 2°C after one hour. After
more than 2 hours, the temperature is permanently
lowered to the set eco temperature.
7.1
Automatic operation
The desired room temperature (comfort temperature)
can be set with the + / - keys.
The presence detection is active. Weekly program with
comfort and lower times can be activated.
7.2
Manual operation
The desired room temperature (comfort temperature)
can be set with the + / - keys.
No presence detection.
Manual specification of the lower temperature (factory
setting lower by 3.5°C).
Manual specification of the frost protection temperature
(7°C).
7.3
Weekly program
Each weekday can be assigned a total of six heating
programs (P1 to P6).
Heating programs P1 to P3 are fixed.
Heating programs P4 to P6 can be set individually.
Each of the heating programs P4 - P6 can be assigned
up to three comfort and three lower times (eco
temperature). Only whole hours can be set. The
executed heating program is shown on the display.
NOTE
For a particularly energy-efficient operation, it is
advisable to run a weekly program.
1802/A
English
EN-4
