Campingaz Plancha L Mode D'emploi page 12

Important :
Check for leaks at least once per year and each time the
gas cylinder is replaced.
g) PRIOR TO USE
Never use the barbecue until the instructions have been
read carefully and understood. Also, make certain that:
- there are no leaks
- the venturi tubes are not blocked (example:
spider webs)
GB
- the hose does not touch any components which may
get hot.
Models
- Plancha EX
- Plancha EXB
Models
- Plancha L
- Plancha LX
- That the cover is not in the closed position (depending
on the model)
- This device has a large number of vents to optimize the
device use. Be sure that these vents are not blocked.
h) LIGHTING THE BURNERS
Read steps 1 to 6 before beginning with step 1.
1) Make sure that the control knobs are in the "OFF"
position (O).
2) Open the gas cylinder valve.
3) Push the adjustment lever down and turn it anticlockwise
until it is in the full flow position (
press the ignition button ( ) down until you hear a click.
Repeat 3 or 4 times if necessary.
4) If the burner does not ignite after 4 or 5 attempts, wait
5 minutes and then repeat the operation.
5) If the device still does not light, place the control knob
in the "OFF" (O) position and wait 5 minutes before
starting the operation again.
6) When the first burner has been lighted, repeat the
operation for the second burner.
Important :
If the burner fails to light after the second attempt, turn the
control knob to the "off" position (O) and check that the
burner outlets and the venturi tube are not blocked.
i) LIGHTING THE BURNERS MANUALLy
If automatic ignition does not work, turn the control knob
to "OFF" (O).
Remove the cooking plate. Hold a lighted match next to
the burner, then push in the control knob and turn it to the
"HI" position (
with protective gloves, being sure to correctly position the
drippings evacuation hole.
j) EXTINGUISHING THE BURNERS
Return the control knobs to the "OFF" position (O), then
close the cylinder valve.
k) REPLACING THE GAS CyLINDER
- Always work in a well ventilated area and never in the
presence of a flame, spark or heat source.
- Return the control knobs in the "off" position (O) then
close the cylinder valve.
- Remove the regulator, check that the sealing joint is in
good condition.
- Put the full cylinder in place, refit the regulator,
taking care not to apply stress to the hose.
Check for gas leaks.
l) OPERATION
PLaNcHa L aND PLaNcHa LX
When operating the grill, the temperature of the substrate
on which the device is placed can be significant. The
appliance must not be installed on a combustible surface
(plastic, cloth, etc ...). It is recommended to place it on a
surface that resists heat (concrete, stone, brick, directly
on the ground) or to position a good thermal/fireproof
insulation between the device and its supporting material.
When used for the first time, heat up the barbecue
(depending on model: remove the lid) with its burners
in full on position (
order to eliminate any odors resulting from the paint on
the new parts.
We recommend using protective gloves for handling
elements that are particularly hot. Use long-handled
utensils to manipulate food on the cooking plate.
Before cooking, preheat the device for a few minutes in
the "HI" position (
Cooking speed can be regulated via the adjustment
buttons: between the full flow position (
flow position ( ).
Important : If one or several burners go out whilst you
are using the barbecue, move the adjustment buttons
to "OFF" immediately (O). Wait five minutes to allow the
unburned gas to escape. Only carry out the lighting steps
after this time.
Important : Allow the unit to cool off completely before
), then immediately
handling the cover (depending on the model).
Spatula : A spatula may
be supplied with the unit
(depending on the model).
When using the unit, the
spatula should be placed
in the slot on the right hand
side of the unit.
12
). Put the cooking plate back in place
), for approximately 15 minutes in
).
) and medium
