K. POWER: Turns amplifier on and off.
L. STANDBY: Disables speaker output while power is on. To extend
tube life, leave switch in STANDBY position for first 60 seconds
after turning POWER (K) on. Instead of turning amp off during
short breaks, set switch to STANDBY position to further extend
tube life and to avoid tube-warmup delay when resuming play.
M. IEC POWER INLET/FUSE: Using the included power cord, con-
nect to a grounded outlet in accordance with the INPUT POWER
voltage and frequency specifed at power inlet. To check/re-
place fuse, unplug power cord and pry fuse holder from power
inlet; replace fuse only with another of the same type and rating.
TYPE
POWER
INPUT IMPEDANCE
OUTPUT IMPEDANCE
SPEAKER
TUBES
FUSE
ACCESSORIES
DIMENSIONS
WEIGHT
For questions and troubleshooting,
contact a Fender specialist at:
1-800-856-9801 (U.S. toll free)
1-480-596-7195 (International)
SPECIFICATIONS
PR2850
Requirements: 270 watts
1MΩ (input 1)
4Ω or 8Ω
One 12" Celestion® Creamback (8Ω)
One pair 6L6GC (power)
F3.15AL 250V (100V-120V models)
Two-button footswitch (included, PN 0994058000)
Width: 22.36" (56.8 cm)
35 lbs. (15.91 kg)
Product specifications subject to change without notice.

REAR PANEL

N. INTERNAL SPEAKER: Jack for internal 8Ω speaker. If connecting
a different speaker to this jack, it should have an impedance of 8Ω
when this is the only jack in use.
O. EXTERNAL SPEAKER: Allows external speaker use in parallel
with internal 8Ω speaker. External speaker must be rated at 8Ω;
output automatically switches to 4Ω when external speaker is
connected.
P. FOOTSWITCH: Connect included two-button footswitch here.
Output: 40 watts RMS into 4Ω or 8Ω @ 5%THD, 1kHz
136kΩ (input 2)
Three 12AX7A (preamp)
F1.6AL 250V (220V-240V models)
Fitted cover (included, PN 7720329000)
Height: 17.25" (43.81 cm)
2
Two 12AT7 (preamp)
Depth: 9.37" (23.8 cm)
