Hooking Up the Optional Components

Connecting audio
components
To the analog
output jacks of
a video game
To the analog
output jacks of
an MD deck/
VCR
To the digital
output jack of
an MD deck
GB
52
To the digital
input jack of
To subwoofer
an MD deck
To the analog
input jacks of
an MD deck/
VCR
To Do This
Make a digital Connect an optional optical
recording from DVD/ cable.
VIDEO CD/CD to
MD
Listen to the digital Press DIGITAL.
sound of a
connected MD deck
Listen to the analog Press MD (VIDEO).
sound of a
connected MD deck
Listen to the analog Hold down MD (VIDEO) and
sound of a connected press ?/1 while the power is
on. Release ?/1 first, then
VCR
release MD (VIDEO). This
switches the function from
MD to VIDEO. Once you
switched to the VIDEO
function, just press MD
(VIDEO).
Listen to the analog Press GAME.
sound of a connected
video game
Tips
• Pressing DIGITAL, MD (VIDEO) or GAME while
the power is off automatically turns the power on.
• When you remove the optical cover, keep it for
future use.
Notes
• Make sure to match the color of the plugs and the
connectors.
• If the sound is distorted or too loud when VIDEO
function is selected, or you want to switch back to
MD function, repeat the operation described above
to switch to MD function.
• Digital signals are output from DIGITAL OUT jack
during DVD or DIGITAL function only. Besides,
the sound output from the DIGITAL OUT jack is
not affected by the sound adjustment.
• This unit is not compatible with 96 kHz sampling
frequencies and SACD format.
