INSTALLATION MANUAL
TERENA - TERENA16
Web Based Access Control
A reNaMe readerS
Allows you to rename the reader in "READER NAME".
uNLOCk tiMe
B
From "1" to "99" seconds or for a latch mode enter "0".
C

LatCH MOde

- Latch mode = "y".
- When a tag is swiped or the request-to-exit
button pressed, the output remains activated
(the door remains unlocked) (LED turns solid green).
- When a tag is swiped or the request-to-exit
pressed, the output is deactivated the door
is locked (the LED starts flashing orange).
Free aCCeSS
D
- Enter "0" to disable the free access.
- Enter a schedule group from "1" to "30".
- Holidays (click to confirm the holidays or not).
- Automatic mode (if a schedule group is defined,
automatic mode enables it to be activated
at the set time.
If the automatic mode is not activated
then the free access starts when the "first man
in" swipes a valid card on the card reader).
cdvi.com
22
cdvigroup.com
A
C
E
F
B
D
G
aNti-PaSSBaCk ON readerS
E
- A reader is assigned or not to a zone
(up to 8 zones).
- Select "Entry" or "Exit" for each reader.
- Allocation of an entry/exit counting zone.
F dOOr StatuS
- If Green = "Yes"; If Red = «No»,
- Possibility of activating these options: indicates
if the door is left open too long. Select Door
Forced Open if you want to monitor a forced
door. (1 to 99 second time delay before alarm
is triggered).
OPeratiNG MOde*
G
- Downgraded mode = permanent closing
and opening if a tag is detected.
- Standalone mode = permanent closing
and opening if a priority tag is swiped and stored
in the reader controller's memory.
- Opening = Permanent opening.
- Closing = Permanent closing.
* Operating mode in the event of loss of communication
with the RS485 BUS.
EN
