INSTALLATION MANUAL
TERENA - TERENA16
Web Based Access Control
QuiCk Start Guide
tereNa & tereNa16
this central unit features a secure shutdown procedure.
if this procedure is not respected or if the battery is missing,
damage may de done to the sd card and its contents:
cdvi may not be held responsible for any loss of data.
Making backup copies of your data is therefore essential.
INSTALLATION
- Make the necessary wire connections for the central unit.
- Connect the cross-over network cable between the central control unit and the PC.
- Ensure that the SD card is properly inserted into the correct slot.
- Check the 4 DIP switch positions: Switches 1 and 4 should be in the ON position
and switches 2 and 3 in the OFF position.
You should never modify the 2-position dip switch terminal (switch 1 is off
and switch 2 is on)
- Connect the battery.
- Connect the central unit and switch it on (with the fuse holder inserted).
- Remove the lithium battery protection (CR2032) and install the battery.
- Wait a few moments and then check that the green light (PWR) comes on next
to the USB socket.
CONFIGURING YOUR PC
Assign a static IP address (IPv4) to the PC network card, for example: address
192.168.0.101, netmask 255.255.255.0 and leave the other fields empty.
CONFIGURING THE CENTRAL CONTROL UNIT
- Open the internet browser on your PC (minimum requirements: IE 8, FireFox 3.6,
Chrome 5, Safari 4 or Opera 10.5), Preferably, we recommend the use of Firefox.
