Product Characteristics; Cleaning And Maintenance - Peg-Perego Duette-Triplette Pop-Up Notice D'emploi

_ WARNING This product is not suitable for running or
skating.
_ Apply the brake when loading or unloading children.
_ For new born babies is recommended to use the
backrest in the most reclined position.

PRODUCT CHARACTERISTICS

_ The item is numbered progressively.
Duette/Triplette Pop Up is a reversible seat that can
face mum or the world.
PRODUCT COMPONENTS
Check all packaging contents and contact the
Customer Help Service if you have a complaint.
Duette/Triplette Pop Up: hood.
INSTRUCTIONS
1 FRONT BAR: To attach the front bar, slide the
attachments into the armrests and push towards
the seat until they lock into place (fig_a). To remove
the front bar, press the two buttons (fig_b) and pull
out (fig_c). Open the front bar on one side only, to
facilitate the child's entry and exit.
2 BACKREST: reclines via the handle located on the
backrest.
3 FOOTREST: before adjusting the footrest, ensure the
footrest cover is duly fitted; if it is not, fasten the
cover.
To lower the footrest, pull the two levers downwards
(fig_a); to raise it, push the footrest upwards (fig_b).
4 SLEEPING POSITION FOR DUETTE ONLY: a cot can be
created by placing the seats facing each other.
Lower the two seats' backrests fully (fig_a); lower the
footrest (fig_ 3a); only raise the leg rest, by pushing
it upwards (fig_b1), ensuring the footrest remains
lowered in the vertical position. Ensure the leg rest is
locked in place by pressing both tabs inwards at the
same time (fig_b2).
To lower the leg rest, press both tabs outwards at the
same time, as shown in the figure (fig_c).
WARNING: The footrest may only be raised when
the seat faces out from the frame.
5 FIVE POINT SAFETY HARNESS: To fasten it, push the
two waist strap buckles (with the shoulder straps
attached – arrow_a) into the leg divider until they click
into place (arrow_b). To unfasten it, press the round
button in the centre of the buckle (arrow_c) and pull
the waist straps out (arrow_d).
6 To tighten the waist strap, pull on both sides in the
direction of the arrow (arrow_a). To loosen it, move it
in the opposite direction.
7 To adjust the height of the safety harnesses, release
the two buckles on the rear of the backrest.
Pull the shoulder straps towards you (arrow_a) until
the buckles are released and insert them in the
backrest loops (arrow_b). Remove the shoulder straps
from the sack (arrow_c) and insert them in the most
appropriate loop (arrow_d), then re-attach the two
buckles on the rear of the backrest (arrow_e) The
buckles are securely attached when a click is heard
(fig_f).
8 HOOD: To fasten, slide the attachments into the sides
of the seat (fig_a) and button the hood to the back
of the backrest (fig_b). To remove the hood: pull out
the attachments and unbutton. To lift the hood: pull
it towards you; to close the hood: push it back. The
hood includes a slot from which you can hang the
child's favorite toy (fig_c).
9 When the backrest is fully reclined, open the hood
using the double slider on the back (fig_a). To provide
your child greater ventilation, lift the hood section
fastened with Velcro (fig_b).
10 FASTENING THE SEAT TO THE FRAME: to ensure the
product is stable, we recommend always installing all
the Pop-Up seats. If for any reason you are using the
product with a single occupant, we recommend you
fasten all the seats in any case, and make sure they are
properly docked.
The Pop Up seat can be secured to the frame either
facing mom or the world. Place it on the frame
alongside the symbols (fig_a). Position it and press
downwards with both hands until it clicks into place.
Make sure the seat has locked into place by pulling it
upwards.
11 RELEASING THE SEAT FROM THE FRAME: press the two
buttons on the armrests of the seat (fig_a) and then
the two levers underneath (fig_b); pull up the seat
(fig_c) until it releases.
12 FOLDING: you can fold up the frame without releasing
the Pop-Up seats (both facing mom). To do this, lower
the backrest of both seats fully forward.
The stroller folds up more compactly if you release
the seats.
13 REMOVING THE COVER: Unbutton the cover along the
armrests (fig_a) and the backrest (fig_b), remove the
cover from the footrest (fig_c), unscrew (fig_d) and
remove the harness on both sides, and finally remove
the crotch strap from above, pushing from under the
seat (fig_e).
ACCESSORY
14 RAIN CANOPY: may be fastened to the hood (fig_a).
MOSQUITO NETTING: can be fastened to the hood
(fig_b).
SERIAL NUMBERS
15 Duette/Triplette Pop Up reports information as at the
date of manufacture of the product.
_ Product name, date of manufacture and serial number
of the seat.
This information is required for any complaints.

CLEANING AND MAINTENANCE

PRODUCT MAINTENANCE: protect from the weather:
water, rain, or snow; prolonged and continuous
exposure to bright sunlight may give rise to colour
changes of various different materials; store this
product in a dry place.
CLEANING THE SEAT: periodically clean all plastic
parts with a damp cloth. Do not use solvent or
similar cleaning products; keep all metal parts dry to
prevent rusting; keep moving parts clean (adjustment
mechanisms, locking mechanisms, wheels, ...) and free
of dust and sand and, if necessary, lubricate with light
machine oil.
CLEANING THE RAIN CANOPY: wash with a sponge and
soapy water; do not use detergents.
CLEANING FABRIC PARTS: brush fabric parts to remove
dust and wash by hand at a maximum temperature of
30°C; do not wring; do not use chlorine bleach, do not
iron; do not dry clean; do not apply solvent-based stain
removers and do not dry in a tumble dryer.
PEG-PÉREGO S.p.A.
Peg-Pérego S.p.A. is an ISO 9001 certified
company. This certification is a
guarantee for customers and consumers
of the transparency and trustworthiness
of the company's procedures and
working methods.
Peg Pérego can make changes at any time to the
models described in this publication for technical or
commercial reasons. Peg Pérego is at the disposal of
its customers and consumers to ensure that all their
demands and queries are fully satisfied. It is a key
part of our policy to ensure we are always aware of
- 11 -
