Load factor:
A load factor of S2 20 min (intermittent periodic
duty) means that you may operate the motor con-
tinuously at its nominal power level for no longer
than the time stipulated on the specifi cations
label (20 min). If you fail to observe this time limit
the motor will overheat. During the OFF period the
motor will cool again to its starting temperature.
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 1870-19.
Operation
L sound pressure level ..................... 95,3 dB(A)
pA
K uncertainty ............................................. 4 dB
pA
L sound power level ..................... 106,8 dB(A)
WA
K uncertainty ............................................. 4 dB
WA
The quoted values are emission values and not
necessarily reliable workplace values. Although
there is a correlation between emission and im-
mission levels it is impossible to draw any certain
conclusions as to the need for additional precau-
tions. Factors with a potential infl uence on the ac-
tual immission level at the workplace include the
duration of impact, the type of room, and other
sources of noise etc., e.g. the number of machi-
nes and other neighboring operations. Reliable
workplace values may also vary from country to
country. With this information the user should at
least be able to make a better assessment of the
dangers and risks involved.
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
Anl_TC_TS_2031_U_SPK9-1.indb 27 Anl_TC_TS_2031_U_SPK9-1.indb 27
GB
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
•
Unpack the bench-type circular saw and
check it for damage which may have occurred
in transit.
•
The machine has to be set up where it can
stand firmly, e.g. on a work bench, or it must
be bolted to a strong base.
•
All covers and safety devices have to be pro-
perly fitted before the machine is switched on.
•
It must be possible for the saw blade to run
freely.
•
When working with wood that has been pro-
cessed before, watch out for foreign bodies
such as nails or screws etc.
•
Before you actuate the On/Off switch, make
sure that the saw blade is correctly fitted and
that the machine's moving parts run smoothly.

6. Assembly

Danger! Pull out the power plug before carry-
ing out any maintenance, resetting or assem-
bly work on the cutting-off machine!
6.1 Assembling the base frame
(Fig. 1a, 2a-e, 3a-b, 4-6)
Danger! Make allowance for the weight of the
machine and arrange another person to help you
if necessary!
•
Turn the bench-type circular over and set
the saw down on the floor or on some other
work surface. Important! Place two pieces
of squared timber between the table surface
and the work surface to prevent any damage
to the projecting splitter of the saw.
•
Use the hex screws (a), washers (c) and nuts
(d) to fasten the legs (29) and the leg (32)
