APPENDIX 3 : CABLE FIXING

Right side or left side
Pressing the nut
with your finger,
re-screw the
knurled screw
just one turn,
then push the
knurled screw to
disengage the
nut from its
position.
Other possibilities
Screw the knurled screw about 2 turns until
the nut remains in place by itself.
Screw until it becomes tight.
You may remove the knurled
screw after the operation.
To dismount:
Push the nut out with
the knurled screw,
Pinch and push the part.
page 37 / 40
Unscrew the knurled screw, taking care
that the nut remains in place
Push
Mounting on the other side
INSTALLATION MANUAL
3300039745 R11 000 04/735
