Precautions when using Heat-Sensitized Paper
As the ticket may deteriorate in the event of improper storage, the following must be avoided:
• Storage in areas that are hot and humid (close to a heater/cooling unit, degree of humidity greater than
85%),
• Long-term exposure to sunlight or ultraviolet rays,
• Contact with organic solvents (solvent-based adhesives),
• Direct contact with material containing softening (plasticizing) agents (envelopes or clear plastic folders
made of PVC),
• Direct contact with whiteprint paper,
• Direct contact with water,
• Rubbing or pressing the paper too strongly.
5. INSTALLING AND REMOVING SECURITY ACCESS
MODULES IN THE EFTsmart

5.1 ACCES TO SAMS (SECURITY ACCESS MODULES)

A SAM is installed in a "SAM support".
The SAM supports are located in a
housing that can be accessed via a
cover flap located on the underside of
the terminal (see figure opposite).
page 27 / 40
INSTALLATION MANUAL
Secondary reader
cover flap
