I N S T R U C T I O N S FO R U S E / E N G L I S H
Charging time lithium pack
rcB 1400
(10020)
lithium pack
rcB 2000
(10095)
S A F E T Y F U N C T I O N S
Short circuit protection: In the event of a short circuit
￭
at the contact or the heating element, the integrated
electronics automatically turn the product off. After
eliminating the short circuit, please briefly connect the
battery packs to the Charge Box. Next, press the control
button once and the product is ready again.
￭ Protection against overcharging and exhaustive
discharge: The product is protected against overcharging
and exhaustive discharge with the integrated electronics
system.
H O W TO U S E T H E B AT T E RY PAC KS
Use with Lenz heat products
￭ Remove the contact protector from the battery packs (Fig.
1.4).
￭ Place the battery packs in the intended position (see figure
A, B, C, D, E).
Push the battery packs onto the snap fasteners until they
￭
audibly lock into place (Fig. F).
￭ The battery packs can be operated conveniently and
manually, either through the visual control window or the
textile (Fig. G), or optionally via the Lenz heat app on a
smartphone.
– 100 –
Normal Fa s t
c h a r g e
8 – 9 h 5 – 6 h
12 – 13 h 7 – 8 h
I M P O R TA N T I N S T R U C T I O N S FO R U S E
• When using the heated product, the optimal heating power
is only produced when all heated products, textiles and
socks you are wearing are dry.
• Do not operate the device at the highest heating power for
longer than several minutes.
• Always set the product to a low or medium heat level to
maintain a comfortably warm temperature (the heating
should be nearly unnoticeable).
F U N C T I O N A L D ES C R I P T I O N
lithium pack rcB 1400 / lithium pack rcB 2000
Manual operation:
The battery packs have three heat settings. They are indicated
by the heat setting display (Fig. 1.2) on the battery packs.
Remote control:
When using remote control via the APP, the heat output can be
set to one of 9 levels via the corresponding controls in the APP.
U S E A N D F U N C T I O N
Turning on:
Turn on the product on the lowest heat setting by briefly
pushing (approximately 0.5 seconds) the control button on
the battery pack (Fig. 1.3).
Setting the heat level:
This can be done by repeatedly pressing the control button
on the battery pack (Fig. 1.3), or using the corresponding
control in the APP when using remote control.
The respective heat level is indicated by the illumination of
the heat setting display (Fig. 1.2) on the battery pack, or in
the APP when using remote control.
low heat level
moderate heat level
high heat level
