2-Channel DI Box
These instructions are intended for users
without any specific technical knowledge .
Please read the instructions carefully prior
to operating the unit and keep them for
later reference . All operating elements and
connections described can be found on the
fold-out page 3 .
1 Operating Elements and
Connections
(for channel A only, channel B is identical)
1 XLR output jack, bal .
2 Groundlift switch
3 Input jack, unbal .
4 Parallel feed-through jack, unbal .
5 Sliding switch to attenuate the input
signal
2 Important Notes
The unit corresponds to all relevant direc-
tives of the EU and is therefore marked
with .
•
The unit is suitable for indoor use only .
Protect it against dripping water and
splash water, high air humidity, and heat
(admissible ambient temperature range
0 – 40 °C) .
•
Only use a dry, soft cloth for cleaning;
never use any chemicals or water .
•
No guarantee claims for the unit and no
liability for any resulting personal dam-
age or material damage will be accepted
if the unit is used for other purposes than
originally intended, if it is not correctly
6
connected or operated, or if it is not re-
paired in an expert way .
If the unit is to be put out of
operation definitively, take it to
a local recycling plant for a dis-
posal which is not harmful to the
environment .

3 Applications

The DI Box (Direct Injection) allows for op-
timal connection of a musical instrument
with a high-impedance, unbalanced out-
put to a low-impedance, balanced input of
a mixer (fig . 2) . By means of the balanced
connection to the mixer, interference can
be avoided even when long connection
cables are used . If hum loops occur, the
ground connection between instrument
and mixer can be separated by means of
the groundlift switch; the devices will be
galvanically isolated .
High signal levels can be reduced by
means of the attenuator and matched to
the mixer input . Thus, the DI Box can also
be connected directly to the speaker out-
put of an instrument amplifier; the effect
of the amplifier on the sound (e . g . guitar
amplifier or tube amplifier) will be main-
tained at the mixer input .
4 Setting the DI Box into
Operation
The DI Box does not need any power sup-
ply . In the text below, only channel A is
described . Proceed in the same way to set
channel B into operation .
