PROGRAM. 1
Make the connections to
1
the vehicle:
Connector 1 (White):
Determine the type of installation:
1.A
- INSTALLATION WITH D2D (See P.1, Plan 1)
- INSTALLATION WITHOUT D2D (See P.1, Plan 2)
Connector 2 (White):
1.B
Make the connections associated with the
vehicle in the VEHICLE FIT GUIDE (P.2-4)
PROGRAMMING
Vehicle equipped with SMART KEY
10'
2
Insert connector 2.
3
Release the programming
button when the LED turns ON.
If the LED is flashing at this point the module is
already programmed and can't be programmed
again. (To prevent malicious use this module can
be programmed in only one vehicle.)
KEY#1
4
KEY#1
5
Remove all keys from key
remote cards.
Keep the card away from
the vehicle (10 feet/3
meters minimum) to
proceed with the
programming procedure.
Keep programming button
pressed while inserting
connector 1.
Insert the first functional
key into the ignition
barrel and turn the
ignition ON.
When the security light
turns OFF, turn the key to
the OFF position and
remove the first key from
the barrel.
FORD / JAGUAR / MAZDA / LINCOLN / MERCURY
SEE VEHICLE FIT GUIDE (P.3) TO IDENTIFY THE SYMBOL.
For the vehicles identif
round symbol
(1 key required)
KEY#1
6
Insert the first
functional key into
the ignition barrel
again and turn the
ignition ON.
KEY#1
7
When the dash board
security light turns
OFF, turn the key to
the OFF position and
remove the first key
from the barrel.
8.a
For MANUAL
Transmission:
Press and hold the
programming button
until the LED flashes
once, then release.
8.b
12V
With a jumper wire,
apply power (12v) to
the vehicles ignition
wire until the dash
board security light
turns OFF. Remove
the jumper.
9
PKALL
DATA IMMOBILIZER OVERRIDE
ied
with
For the vehicles identified with
square symbol
(2 key required)
The following
procedure must be
completed in 3 to 5
seconds:
KEY
6
Insert the second
functional key into the
ignition barrel and turn
the ignition ON.
KEY
7
When the dash board
security light turns
OFF, turn the key to the
OFF position and
remove the second key
from the barrel.
The following procedure must be
completed in 3 to 5 seconds:
For AUTOMATIC
Transmission:
Press and hold the
programming button
until the LED flashes
once, then release.
Ignition
8.b
Activate the remote
starter.
If the LED flashes 10
times, the module is
programmed.
If the LED turns ON, repeat
from step 1.
#
2
#
2
P.13
