LED Module Diagnostics :
On: Activated.
OFF: Not activated.
Flash: Not programmed.
Purple/White
Yellow/Black
Blue/White
Green
Pink
Black
1
INSTALLATION
WITH
Front view of the module
INSTALLATION
WITHOUT
Cut off one plug of the D2D connector, connect the BLUE wire to +12V and the BLACK wire to ground
*Wire colors may vary for the kit you purchased.
20 pin connector
10 9
8
7
6
5
4
3
1
10 9
18 17 16 15 14 13 12 11
Located under dash,
left side of steering
column.
CUT
Brown/White or Pink
(Security light)
Connector 4 (White -
4 pins
):
Connect with th XK Loader for web update.
Connect wire to Remote-Starter/Alarm
HYUNDAI XG350
White connector located under dash,
right side of diagnostic connector (OBDII)
Data
N.c.
2
(-) While running
N.c.
Ignition
N.c.
Connector 1 (White) - 4 pins):Determine the type of installation:
Blue*
conn.
D2D connector
White*
Black*
D2D
Red*
Blue*
+12V
White*
Ground
Black*
D2D
Red*
8
7
6
5
4
3
1
18 17 16 15 14 13 12 11
Relay 1a
Light Green
3
Relay 1b
Orange/Brown
Orange/Green
N.c.
conn.
N.c.
4
XK Loader connector*
conn.
* Connector not supplied
Connect wire to vehicle
TECHNICAL
TECHNICAL
SUPPORT
SUPPORT
INFORMATION
INFORMATION
2002-2005
1
2
3
4
5
5
6
6
7
7
8
8
9 10
9 10
CAUTION: Be careful NOT to
plug connector into the Black port
which also accepts a 4-pin
connector.
conn.
Brown
Back view of the module
INPUT
OUTPUT
web resources:
www.xpresskit.com
www.xpressvip.com
www.directechs.com
U p d at e
A l e r t : F i r m w a r e
updates are posted to the web on
a regular basis. We recommend
WWW.XPRESSKIT.COM
you check for firmware and/or install guide
updates prior to installation of this product.
1
Make the connections to the vehicle:
Connector 1 (White):
1.A
Determin the type of installation:
- INSTALLATION WITH D2D
- INSTALLATION WITHOUT D2D
Connector 2 (White): Make the connections
1.B
Connector 3 (White): Make the connections
Press and hold the programming button.
2
Insert connector 1.
Insert connector 2.
If the LED is flashing at this point the module is
3
already programmed and can't be programmed
again. (To prevent malicious use this module can
be programmed in only one vehicle.)
While holding the programming button.
4
Insert connector 3.
5
Release the programming button
when the LED turns ON.
Press 1 time on the programming button.
6
The LED turns OFF and turns ON.
7
Press 2 more times on the programming
button and the LED will flash twice.
8
Turn the Ignition to the ON position.
If the LED flashes 10 times, the
module is programmed.
9
If the LED stays ON, verify your connections
and repeat from step 1.
10
Turn the Ignition key to the OFF position.
Remove the key and start the vehicle using the
11
remote starter to ensure functionality.
PKALL
Rev. 20100120
