Directed Electronics XPRESSKIT PKALL Mode D'emploi

FORD Mustang
LED Module Diagnostics :
On: Activated.
OFF: Not activated.
Flash: Not programmed.
Purple/White
Yellow/Black
Blue/White
Green
Pink
Black
1
Connector 1 (White) - 4 pins):Determine the type of installation:
Front view of the module
INSTALLATION
Cut off one plug of the D2D connector, connect the BLUE wire to +12V and the BLACK wire to ground
*Wire colors may vary for the kit you purchased.
4 pins
Connector 4 ( ):
Connect with the XK-Loader for web update.
Connect wire to Remote-Starter/Alarm
Rx (Data In)
conn.
Tx (Data Out)
2
(-) While running
N.c.
Ignition
N.c.
Blue*
D2D connector
White*
WITH Black*
D2D
Red*
Blue*
+12V
White*
INSTALLATION
WITHOUT Black*
Ground
D2D
Red*
N.c.
3
Orange/Brown
N.c.
Orange/Green
N.c.
conn.
N.c.
4
XK-Loader
conn.
Connect wire to vehicle
TECHNICAL TECHNICAL
SUPPORT SUPPORT
INFORMATION INFORMATION
2005-2009
4 3 2 1
Igniton barrel
PIN # DESCRIPTION
1 IGNITION +12V (N.C.)
2 GROUND (N.C.)
3 TX (Data)
4 RX (Data)
CAUTION: Be careful NOT to
1
plug connector into the Black
port which also accepts a 4-pin
connector.
Light Green
Brown
Back view of the module
INPUT
OUTPUT
web resources:
www.xpresskit.com
www.xpressvip.com
www.directechs.com
U p d a t e A l e r t : F i r m w a r e
updates are posted to the web on
a regular basis. We recommend
WWW.XPRESSKIT.COM
you check for firmware and/or
install guide updates prior to installation of
this product.
1
Make the connections to the vehicle:
Connector 1 (White):
1.A
Determin the type of installation:
- INSTALLATION WITH D2D
- INSTALLATION WITHOUT D2D
1.B
Connector 2 (White): Make the connections
PROGRAMMING Vehicle equipped with SMART KEY
Remove all keys from key
remote cards.
Keep programming button pressed
2
while inserting connector 1.
Insert connector 2.
Release the programming button when the LED turns ON.
3
If the LED is flashing at this point the module is already Programmed
and can't be programmed again. (To prevent malicious use this module
can be programmed in only one vehicle.)
KEY#1
4 Insert the first functional key into
the ignition barrel and turn the ignition ON.
KEY#1
When the security light turns OFF, turn the key to
5 the OFF position and remove the first key from the barrel.
You have 5 seconds to complete the
following procedure
KEY # 2
6
Insert the second functional key into the
ignition barrel and turn the ignition ON.
KEY # 2
When the dash board security light turns OFF,
7
turn the key to the OFF position and remove the
second key from the barrel.
You have 10 seconds to complete one
8.a
of the following procedures
For MANUAL Transmission:
8.b
Ignition
Press and release the
12V
programming button.
The LED will flash 1 time.
For AUTOMATIC Transmission:
8.b
If the LED flashes 10 times, the module is
9
programmed.
If the LED turns ON, repeat from step 1.
PKALL
Rev.: 20100122
10'
Keep the card away from the vehicle
(10 feet/3 meters minimum) to proceed
with the programming procedure.
With a jumper wire, apply power
(12v) to the vehicles ignition wire
until the dash board security
light turns OFF.
Remove the jumper.
Activate the remote starter.
