2 Paramètre de fonctionnement
MENU > OPERATION PARAMETER
Ce menu a été conçu pour que l'installateur ou le réparateur vérifie le paramètre de fonctionnement.
Paramètre de fonctionnement
OPPERATION PARAMETER
ONLINE UNITS NUMBER
ODU MODEL
OPERATION MODE
FREQUENCY ORDER
FREQUENCY LIMITED TYPE
COMP. RUN TIME
ADDRESS
OPPERATION PARAMETER
TW_I PLATE W-INLET TEMP.
TW_O PLATE W-OUTLET TEMP.
T1 LEAVING WATER TEMP.
TW2 CIRCUIT2 WATER TEMP.
Ta ROOM TEMP.
RH ROOM HUMIDITY
ADDRESS
OPPERATION PARAMETER
DC GENERATRIX CURRENT
POWER CONSUM
SV
SV2
SV3
PUMP_I
ADDRESS
OPPERATION PARAMETER
IHB2 TOTAL RUN TIME
THB TOTAL RUN TIME
AHS TOTAL RUN TIME
IDU SOFTWARE 29-09-2021V15
ODU SOFTWARE 28-09-2021V25
HMI SOFTWARE 16-10-2021V19
ADDRESS
#00 OPPERATION PARAMETER
1 COMP. FREQUENCY
16 kW FAN SPEED
COOL EXPAN VALVE
ON Tp COMP. DISCHARGE TEMP.
0 Th COMP. SUCTION TEMP.
1 MIN T3 OUTDOOR EXCHANGE TEMP. 42°C
1/10 ADDRESS
#00 OPPERATION PARAMETER
23°C T5 WATER TANK TEMP.
20°C T5_2 WATER TANK TEMP.
- -°C Tbt BUFFER TANK TEMP.
- -°C Tsolar
- -°C T1S' C1 CLI. CURVE TEMP.
- -% T1S2' C1 CLI. CURVE TEMP.
4/10 ADDRESS
#00 OPPERATION PARAMETER
9 A PUMP_O
53 kWh PUMP_C
PUMP_S
OFF
PUMP_D
OFF
IBH1
OFF
IBH2
ON
ADDRESS
7/10
#00
0 Hrs
- - Hrs
0 Hrs
10/10
