MOUNTING THE GUARD
WARNING:
Always wear gloves when mounting or
EN
replacing the guard. Take care of the blade on the guard
and protect your hand from cutting.
WARNING:
Never operate the tool without the
guard firmly in place. The guard must always be on
the tool to protect the user! When the guard was fixed,
never attempted to remove or adjust the guard, if replace
needed, it shall be performed by a qualified service
technician!
Loosen and remove the two screws from the shaft base
(Fig. B), align the guard mounting holes with the assembly
holes and then lock the guard onto the shaft base with
the two screws, together with two spring washers (Fig. C).
Make sure the guard is fixed according to Fig. B & C, any
reverse fixing will cause great danger!
MOUNTING AND ADJUSTING THE FRONT-ASSIST
HANDLE
Push the front-assist handle onto the shaft (Fig. E), then
insert the clamping block into the handle slot (Fig. F),
mount the lock pole, and lock them with the wing nut (Fig.
G). The sequence is as Fig. D shown. Lastly, adjust the
front-assist handle position to make sure your front arm
is straight when using the trimmer ( Fig. H) and then lock
the lever of the lock pole (Fig. I )
Fig. D & H parts description see below:
D-1 Front-assist Handle
D-2 Lock Pole
D-3 Clamping Block
NOTICE:
The front-assist handle should be turned
upwards to point toward the top of the handle.
WARNING:
Only fix the front-assist handle in front
of the soft sleeve on the shaft.
WARNING:
The tool can not be used without the
front-assist handle reliably fixed.
MOUNTING THE SHOULDER STRAP
Loose the bolt in the hook of the strap (Fig. J & K), attach
the hook onto the shaft and lock it with the bolt (Fig. L & M).
WARNING:
Only fix the hook of the strap between the
housing and the soft sleeve on the shaft.
10
56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1500E
D-4 Wing Nut
H-1 Soft Sleeve
H-2 Warning Label
OPERATION
WARNING:
Do not allow familiarity with this
product to make you careless. Remember that a careless
fraction of a second is sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side
shields. along with hearing protection. Failure to do so
could result in objects being thrown into your eyes and
other possible serious injuries.
WARNING:
Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING:
Use your line trimmer equipped with the
appropriate cutting line only for cutting grass and similar
material.
You may use this product for the purposes listed below:
Trimming: used for removing grass and weeds up against
walls, fences, trees and borders.
Cutting: used for cutting the grass that is difficult to
reach using a normal mower.
NOTICE:
The tool is to be used only for its prescribed
purpose. Any other use, for example edge trimming, is
deemed to be a case of misuse.
ATTACHING/DETACHING THE BATTERY PACK
Fully charge before first use.
To Attach
Align the battery ribs with the mounting slots and press the
battery pack down until you hear a "click" (Fig. N).
To Detach
Depress the battery-release button and pull the battery
pack out as Fig. O shown.
HOLDING THE LINE TRIMMER
WARNING:
Dress properly to reduce the risk of
injury when operating this tool. Do not wear loose
clothing or jewelry. Wear eye and ear/hearing protection.
Wear heavy duty, long trousers, boots and gloves. Do not
wear short trousers, sandals or go barefoot.
Before operating, stand in the operating position and
check for eye protection, proper clothing, balanced foot-
ing, straight arm, which holds the front-assist handle.
