ASSEMBLY
WARNING
all battery packs before removing the tank.
NOTICE
Keep filter clean. Efficiency of
the vacuum is largely dependent
on the filter. A dirty filter will reduce the air flow
and overall efficiency of the system. Remove
from tank and tap clean.
WARNING
the battery. For specific charging instructions,
read the operator's manual supplied with your
charger and battery.
Removing/Inserting the Battery
To remove the battery, push in the release buttons
and pull the battery pack away from the tool.
WARNING
tool is not in use.
To insert the battery, slide the pack into the body
of the tool. Make sure it latches securely into place.
VACLINK™
(Cat. No. 0914-20 and 0926-20 only)
VACLINK™ is a wireless dust control technology that
allows a compatible tool and vacuum to connect to
each other.
A signal from the tool will turn the vacuum on and off.
The tool can be connected to one vacuum at a time.
The vacuum can be connected to multiple remotes
or tools at at time.
NOTE: Other product's VACLINK™ functionality may
differ. See those instructions for more information.
Pairing a VACLINK™ Remote
If the VACLINK™ remote is not connected to the
vacuum, pairing can be setup by:
1. Insert battery pack(s) into the vacuum.
2. Press the VACLINK™ button on the vacuum and
the remote until both LED's begin to flash. A steady
green light on both the vacuum and the remote
will confirm that the unit is paired. NOTE: Remote
needs to be within close proximity to ensure
remote is receiving signal from the the vacuum.
This procedure will time out after 30 seconds if
the vacuum is not paired and will enter standby
mode for inactivity.
To confirm that the remote has paired with the
vacuum successfully, press the VACLINK™ button on
remote and the VACLINK™ button on the vacuum will
light. Multiple remotes can be paired to one vacuum.
To reduce the risk of
injury, always remove
Recharge only with the
charger specified for
Always remove all bat-
tery packs any time the
Pairing a VACLINK™ Tool
Consult the VACLINK™ tool's manual for pairing to
the 0914-20 or 0926-20.
1. Install a battery pack on the tool and connect the
vacuum to a power source.
2. To pair, press and hold the pairing buttons on the
tool and vacuum each for 1 to 3 seconds. Hold
for longer than 3 seconds to cancel the pairing.
VACLINK™ LED:
• Searching - Flashing green
• Paired - Solid green
3. See "Troubleshooting" if tool and vacuum do not
pair successfully.
4. To unpair, press and hold the pairing buttons on
the tool and vacuum each for 1 to 3 seconds. Hold
for longer than 3 seconds to cancel the unpairing.
VACLINK™ LED:
• Unpaired - Off
Unpairing VACLINK™ from all connected devices
1. To remove/erase all paired devices from vacuum,
press and hold the VACLINK™ button on the re-
mote until the LED has a flashing red light.
2. Press and hold the VACLINK™ button on the
vacuum until the LED has a flashing red light.
If the remote and the vacuum are not paired after
30 seconds, this procedure will time out and enter
standby mode for user inactivity.
Removing/Installing the Filters
Use the high efficiency filter for dry pickup only. Use
the foam filter for wet pick-up operation only.
1. WARNING! Remove all battery packs to avoid
starting the tool.
2. Release the tank latches and lift off the vacuum
motor head. Place it upside down on a flat surface.
3. To remove the filter, turn it 1/2" counter clockwise
and pull it off of the vacuum motor head/float cage.
4. Empty all debris from the tank.
NOTICE
to the disposal of silica dust.
5. To install the filter, slide it over the float cage.
Line up the filter tabs with the vacuum motor head
notches and turn it 1/2" clockwise to lock in place.
6. Replace the vacuum motor head and secure both
latches.
5
When applicable, adhere to
jobsite guidelines pertaining
