TFA_No. 35.1122_Anl.
07.09.2012
MODUS PLUS – Wireless weather station
7.4 Activate/turn off the different alarm times
• To activate or deactivate the alarm function press the ALARM button in
the setting mode.
• In normal mode appears or disappears the corresponding symbol
+
or no alarm symbol appears.
• When the alarm time is reached, the alarm will ring. The backlight turns
on for a short time.
• If the alarm is not stopped, the increasing alarm will automatically turn
off after 2 minutes and will be reactivated at the same time.
• When the alarm rings, press the SNOOZE button and the snooze function
is activated.
• The backlight turns on for a short time.
• The corresponding alarm symbol flashes.
• The alarm will be interrupted for 5 minutes.
• When the snooze function is activated, a button operation is not possi-
ble. You can only activate the backlight by pressing the SNOOZE button.
• Press the ALARM button to stop the snooze function.
7.5 Maximum and minimum values
• Press once the MAX/MIN button.
• The maximum values
for outdoor and indoor will appear.
• Press the MAX/MIN button again.
• The minimum values
for outdoor and indoor will appear.
• Press and hold MAX/MIN button in the respective mode to clear the
recorded values.
• The actual values appear on the display.
7.6 Weather forecast symbols
• There are 5 different weather symbols:
Sunny
Partly
cloudy
• The weather forecast relates to a range of 12 to 24 hours and indicates
only a general weather trend. For example, if the current weather is
cloudy and the rain icon is displayed, it does not mean the product is
faulty because it is not raining. It simply means that the air pressure has
dropped and the weather is expected to get worse but not necessarily
rainy. The accuracy is about 70 %.
• The sun symbol also appears at night if there is a starry night.
7.7 Temperature indication
• Press the ▼/UNIT button to select temperature display in °C (Celsius) or °F
(Fahrenheit) as the temperature unit.
20
14:18 Uhr
Seite 11
Cloudy
Rainy
Strong
rain
MODUS PLUS – Wireless weather station
7.8 Weather trend pointer
• The trend pointer displayed on the LCD indicates if the atmospheric pres-
sure is increasing, decreasing or steady.
,
,
7.9 Indication of actual moon phase
• The moon phase of each day is shown on the LCD:
A
B
C
A: New Moon
C: First Quarter
E: Full Moon
G: Last Quarter
7.10 Backlight
• Press the SNOOZE button. The backlight turns on for 10 seconds.
7.11 Outdoor transmitter
• The outdoor transmitter will automatically transmit outdoor values to
the basic unit on channel 1 after batteries are inserted.
• After successful installation close the battery compartment of outdoor
transmitter carefully.
• Please reset the instrument and follow the battery installation procedure
if the outdoor transmitter does not work properly. Change the batteries.
7.12 Additional transmitters
• After inserting the batteries into the outdoor transmitter the transmitter
will automatically transmit the outdoor values to the weather station on
channel 1.
• For having more than one outdoor transmitter, select a different channel
(1 to 3) for every outdoor transmitter by pressing the CH button on the
transmitter while the LED is flashing (after starting up of the transmit-
ter). Press once for channel 2 and twice for channel 3. The LED is flashing
once for channel 1, twice for channel 2 and three times for channel 3.
• Press and hold the ▲/CH button on the basic unit for two seconds to start
initialization manually. The channel number on the display appears. The
reception symbol and -.-- flash. The reception of the new outdoor trans-
mitter will be received automatically.
• If you have installed more than one outdoor transmitter, press the ▲/CH
button to change between the outdoor transmitters.
• You can also choose an alternating channel display. Press the ▲/CH button
three times until the circle symbol
• To deactivate the function press the ▲/CH button again and the symbol
disappears.
D
E
F
G
B: Waxing Crescent
D: Waxing Gibbous
F: Waning Gibbous
H: Waning Crescent
appears for alternating channel.
H
21
