ZAPTEC Pro
I förpackningen
Frontlock/
A
Frampanel –
ZM000185
B
Laddstation – ZM000437
Levereras med bakpanelen
Kopplingsdosa
Bakplatta med kopplingsdosa
F
– ZM000438
Verktyg som krävs för installation
x 1
T10
T10 Torx-skruvdragare
eller -bit
44
Kabelingång
x 1
4 mm
4 mm Unbraco-
skruvdragare eller -bit
C
SmartKey – ZM000278
D
Användarmanual – ZM000325
Unik PIN-kod för att konfigurera
E
enheten i ZAPTEC-appen.
Liten tätningshylsa (10–16mm) – ZM000180
