ZAPTEC Pro Manuel D'installation page 10

English
ZAPTEC Pro
In the box
Front cover
A
– ZM000185
Charging station – ZM000437
B
Supplied with the back plate
Junction box
Back plate with junction box
F
– ZM000438
Tool which is required for installation
x 1
T10
T10 Torx screwdriver
or bit
10
Cable entry
x 1
4 mm
4mm Unbrako
screwdriver or bit
C SmartKey – ZM000278
D User manual – ZM000325
Unique PIN code to configure
E
the device in the ZAPTEC app
G Small sealing cone (10–16mm) – ZM000180
Dept. Technical reference Created by Approved by
Fredrik Ostrem 01.08.2017
Document type Document status
Title DWG No.
ZCS_Sealing_Cone_8mm_v1
Rev.
Large sealing cone (16–21mm) – ZM000174
H
Dept. Technical reference Created by Approved by
Fredrik Ostrem 01.08.2017
Document type Document status
Title DWG No.
Untitled
Rev.
I Blanking plug for sealing cone – ZM000173
J Locking nuts - ZB100049
K Adhesive sticker to protect connections
x 1
7 mm
7 mm-long socket
spanner
x 1
x 1
x 1
x 1
x 1
Date of issue Sheet
1/1
x 1
Date of issue Sheet
1/1
x 4
x 1
8 mm
8 mm-long socket
spanner
x 1
