2
Align the holes of the accessory to be installed
EN
with the pins of the multifunction head.
3
SV
Hold the accessory and the accessory adapter
against the multifunction head and turn the
accessory lock back. (Figure 3)
NO
3.3 To install or replace sandpaper
to the product
PL
Warning! Stop the product,
come to a complete stop and
DE
before you install or replace sandpaper to the product.
Note! When you replace or adjust the position of the
FI
sandpaper, pull off the sandpaper carefully from one of
the corners.
FR
1
Remove dirt and unwanted objects from the
sanding pad.
NL
2
Align the holes in the sandpaper with the holes of
the sanding pad and attach the sandpaper to the
sanding pad.
3.3.1 Sandpaper guide
The higher G-number on the sandpaper, the smaller the
grit. The applicable sandpaper depends on the type of
surface, the quantity of material to be removed, and the
wanted finish.
Type
Grit
Coarse
<G80
G80
Medium
G100
G120
Fine
G220
Extra
>G220
fine
8
let the moving parts
and remove the battery
Use
Removal of paint
Rough sanding of wood
To make textured surfaces
Removal of marks
Final sanding of wood
Between coats of paint
To make surfaces smooth
Removal of minor scratches
Polishing of metal
For smooth, polished finish
Between coats of varnish
For the smoothest finish
3.4 To use the product to sand
Warning! Dust caused by the operation of the
product can be harmful to health, flammable or explosive.
Use a dust filter mask or a dust collector.
Warning! Keep the work area clean. Make sure
that the product and the workpiece do not get too hot
because of the risk of fire. Sparks, hot workpieces and
other heat sources can cause ignition of the dust. The
dust from some alloys can catch fire or explode. Mixtures
of materials increase the risk of
Caution! Do not use the same sand paper to metal
and wood to prevent damage to the surface of the wood.
Note! Do a test before operation on the workpiece.
● Do not use the product without sandpaper.
● Do not use force during operation. Too much pressure
can cause damage to the sandpaper and decrease the
life span of the product.
● Make sure that the edge of the sanding pad does not
come into contact with the workpiece to prevent
damage to the sanding pad.
1
Hold the product tightly and make sure that the
sanding pad does not touch the workpiece.
2
Set the power switch to "I" and let the product get
to its maximum speed.
3
Put the sanding pad flush and lightly to the
surface to be sanded.
4
To stop the product, set the power switch "0".
3.5 To use the product to saw
Warning! Hold the product by the insulated grips
during operation in areas where the saw blade can come
into contact with concealed electrical cables. Contact
with live wires will cause the metal parts on the tool to
become live, which can cause electric shock.
Caution! Before operation, make sure that the saw
blade is straight and not damaged, and that there are no
nails and screws in the cut line.
1
Safety the workpiece with a clamp, vice or
equivalent.
ignition.
