EN
1
INTRODUCTION
1.1
PURPOSE
You may use this product for cutting purposes:
•
cutting all types of wood
•
cutting plastic
•
cutting metals
1.2
OVERVIEW
Figure 1.
Trigger
1
Tube
2
Angle Adjustment
3
Trigger
Footplate
4
Blade Orbit
5
Selector Lever
2
GENERAL POWER TOOL
SAFETY WARNINGS
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
3
ASSEMBLY
This section describes how to assemble and adjust the
product.
CAREFULLY READ AND UNDERSTAND THE
SAFETY CHAPTER AND THE ASSEMBLY
INSTRUCTIONS BEFORE YOU ASSEMBLE THE
PRODUCT.
3.1
INSTALL THE BLADE
Figure 3.
1. Remove battery pack.
2. Rotate the blade clamp lock counterclockwise. Hold
the lock in the open position.
3. Insert saw blade between blade clamp and saw bar.
4. Close blade clamp lock.
5. Reinstall the battery pack.
Blade
6
Edge Guide Knobs
7
Edge Guide
8
Finger Guard
9
10 Lock-off Button
WARNING
WARNING
English
3.2
REMOVE THE BLADE
Figure 3.
1. Remove battery pack.
2. Rotate the blade clamp lock counterclockwise. Hold
the lock in the open position.
3. Remove the saw blade.
3.3
INSTALL THE EDGE GUIDE
Figure 4.
Put the edge guide through the two slots in the base of
the machine.
Adjust to the necessary width and lock in place with the
edge guide screw.
4
OPERATION
This section describes how to operate the product.
CAREFULLY READ AND UNDERSTAND
THE SAFETY CHAPTER AND OPERATION
INSTRUCTIONS BEFORE YOU OPERATE THE
PRODUCT.
4.1
INSTALL THE BATTERY PACK
Figure 2.
•
If the battery pack or charger is damaged, replace
the battery pack or the charger.
•
Stop the machine and wait until the motor stops
before you install or remove the battery pack.
•
Read, know, and follow the instructions in the
battery and charger manual.
1. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
2. Push the battery pack into the battery compartment
until the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
4.2
REMOVE THE BATTERY PACK
Figure 2.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
4.3
START THE MACHINE
Figure 5.
The machine can not work when the lock-off button is
on the center.
4
WARNING
WARNING
NOTE
