Date And Time; Language; Display - Fenix V24 WIFI Guide D'utilisation

Start Date Screen
Set the selected parameter (inversely backlit) using the
(+) or (-) buttons; move the cursor to the next
parameter using the (<)(>) buttons at the edges of the
screen and validate when OK
Return Date Screen
Same screen as for Start Date Screen
Vacation Mode Screen
OFF Mode: Your whole heating system will be
switched off.
Important: If this mode is used in the winter
period, there is a danger of the temperature dropping
below freezing point in the building and the subsequent
occurrence of damage – give preference to the Non-
freezing mode in this period.
Non-Freezing Mode: All zones will maintain the
set non-freezing temperature – a different value can be
set for each zone.
At Home: The same program mode as is set for
Sunday will be maintained in all zones until the date of
return. This setting is usually used in cases when you
stay at home during your holiday and the building is
used in a similar way as on Sunday for the whole
period.
Select the required mode for the duration of your
holiday by pressing the corresponding symbol. The
button will be highlighted. Then validate settings with
the button at the bottom right corner.
You can easily end the Vacation mode before the set
return date by pressing the holiday button
... and pressing the "STOP" button.
3.1.3

Date and Time

Setting the date and time – set the selected parameter
(inversely backlit) using the (+) or (-) buttons; move the
cursor to the next parameter using the (<)(>) buttons
3.1.4

Language

See First Installation to set Language
3.1.5

Display

Select the required configuration by pressing the
relevant button directly (the selected value is framed in
blue)
1) "Colour" – selection of backlight colour –
Green/Blue/Grey/Red
2) "Clean display" – after pressing the button the
display will remain inactive for 10 seconds, which
enables it to be cleaned with a suitable cleaning agent
3) "Display lock" – selection of automatic or manual
locking for the touch screen
3a) Display lock – Manual mode
Press the small padlock icon on the main screen.
On the new screen, press the "Lock" button to lock the
display.
The locking of the display is signalled by a red padlock
icon that blinks at each press on the screen. You can
activate the display by pressing this icon and pressing
5 seconds on the button.
