Anchor the Safe
1
Hole Fixing Layout
D
H2
H1
2
Use table
D
above to
measuring
the hole
H2
position.
H1
5
GB
Anchor the Safe
FR
Ancrer le co re-fort
DE
Verankerung des Safes
NL
De kluis verankeren
IT
Ancorare la cassaforte
ES
Anclar la Caja Fuerte
PT
Fixa o cofre
PL
Zakotwicz sejf
20 mm
W
3
W
6
10
RU
SE
Förankra kassaskåpet
NO
Forankring av safen
DK
Forankring af pengeskabet
FI
Kiinnitä kassakaappi
ID
Menambatkan Brankas
CN
AR
24 mm
Europa Grade VI Hole Fixing layout
Ext. Dimension
Size
Width
Depth
W(mm)
D(mm)
M-115
688
633
M-180
688
633
M-275
688
773
M-345
688
773
M-505
923
663
M-640
923
773
7
Hole Fixing
Width
Width
H1(mm)
H2(mm)
404
311
404
311
404
311
404
311
520
311
520
311
4
