Installation, cont'd.
Quick Connect Option
4A.1 4A.2
4A
Cover the wires for protection from foreign objects and
AVISO AVIS
! ! ! ! NOTICE ATTENTION ATENCIÓN CAUTION DANGER
water.
ATTENTION ATTENTION ATTENTION
Ref. Description
4A RV Power Source
4A.1 Positive Battery Terminal
4A.2 Ground Lug / Chassis Ground or negative battery
terminal
K1 Pump Assembly
K1.4 Pump Red Wire
K1.5 Pump Black Wire
K3 Quick Connects
K4 Fuse Holder / 35AMP Fuse
®
Turbo - Model 300
SANICON
Fig. 4
Pump Assembly
K4
K3
Black wire connects to
negative terminal of battery
or vehicle "ground"
5
K1.4
RED power wire & fuse from
battery to switch box
K1.5
Install Quick Connect
Refer to Fig. 1 and Fig. 4.
1. Locate the power source (battery or other main power source)
where the electrical connection will be made.
2. Disconnect positive wire(s) to the RV battery
3. Cut the alligator clips (K5)
4. Cut the fuse holder (K4)
use.
5. Attach the pump
(K1)
the wire leads on the pump to the desired length.
6. Cut the quick connect wiring (supplied) in half.
7. Crimp a quick connect plug onto the pump
Make sure the quick connect plug for the pump has the
NOTICE
socket end for the negative (black) wire.
8. Route a positive wire from the power source to a location near
the RV's drain outlet.
9. Crimp the fuse holder
(K4)
near the power source.
10. Route a negative wire from the battery's negative terminal, or
a ground lug on the RV, or an OEM provided chassis ground
to a location near the RV's drain outlet.
Make sure the quick connect plug going to the power
NOTICE
NOTICE source has the socket end for the positive (red)
wire.
11. Crimp on a quick connect plug to the wire leads.
12. Protect all the wiring for the SANICON® system with a wire
sheath (not provided).
13. Reconnect positive wire(s) that was removed in Step 2 of this
procedure to the RV's battery.
.
(4A)
off of the wire leads on the pump.
off of the red wire and save for later
to the RV's drain outlet
(5A)
leads.
(K1)
(Step 4) on to the positive wire
97571 Rev. C (07/10/2017)
