Model T1000
T1000
OPERATING INSTRUCTION MANUAL
DO NOT OPERATE THE T1000 TOOL UNTIL YOU HAVE READ THIS MANUAL AND
RECEIVED THE PROPER TRAINING ACCORDING TO ANSI STANDARD A 10.3-1995.
PRIOR TO OPERATING THE T1000 TOOL,
STUDY THIS MANUAL CAREfULLY AND DEVELOP A THOROUGH
UNDERSTANDING Of THE CONTENTS.
PROPER TRAINING ACCORDING TO THE CURRENT ANSI STANDARD A
10.3, SAfETY REqUIREMENTS fOR POwDER ACTUATED fASTENING
SYSTEMS MUST bE COMPLETED AND A D
OPERATOR CARD MUST bE ObTAINED PRIOR TO OPERATION Of
THE TOOL. STATE, LOCAL, OR OTHER REGULATIONS SHOULD ALSO
bE fOLLOwED. LAwS, REGULATIONS, AND STANDARDS REGARDING
THE USE Of POwDER ACTUATED TOOLS MAY PERIODICALLY bE
REVISED. ANY SUCH REVISIONS MAY CHANGE THE SAfETY AND
OPERATING PROCEDURES DESCRIbED IN THIS MANUAL. D
INC. IS NOT RESPONSIbLE fOR ANY SUCH REVISIONS wHICH OCCUR
AfTER PUbLICATION Of THIS MANUAL. IT IS THE RESPONSIbILITY
Of THE USER TO MAINTAIN fAMILIARITY wITH THE CURRENT LAwS,
REGULATIONS, AND STANDARDS THAT APPLY TO THE POwDER
ACTUATED TOOL.
TO AVOId SERIOUS INjURy OR dEATh:
NEVER CLOSE TOOL wITH ANY PART Of HAND OVER
MUzzLE END.
OPERATORS AND bYSTANDERS MUST wEAR
EYE AND HEARING PROTECTION.
ALwAYS ASSUME TOOL IS LOADED. DO NOT
PLACE A fINGER ON THE TRIGGER Of LOADED TOOL
UNTIL MUzzLE END IS AGAINST wORk SURfACE AND
YOU ARE READY TO MAkE A fASTENING.
NEVER PLACE YOUR HAND OVER THE MUzzLE wITH A
POwDER LOAD IN THE TOOL. If THE TOOL
ACCIDENTALLY DISCHARGES THE PISTON
OR fASTENER MAY PENETRATE YOUR HAND
RESULTING IN SERIOUS INjURY.
IT IS VERY IMPORTANT THAT THE OPERATOR Of THIS TOOL
COMPLETELY READS AND UNDERSTANDS THE ENTIRE TOOL
MANUAL AND COMPLETES THE OPERATOR'S ExAM ON THE LAST
PAGE. THE wARRANTY wILL NOT bE VALID UNTIL THE TEST IS
RECEIVED, wITH A COPY Of YOUR RECEIPT, AND REVIEwED bY
D
wALT, INC.
E
T1000
All manuals and user guides at all-guides.com
wALT qUALIfIED
E
E
Low Velocity Powder
Actuated Fastening Tool
Warranty
Three Year Limited Warranty
D
wALT will repair, without charge, any defects due to faulty
E
materials or workmanship for three years from the date of
purchase. This warranty does not cover part failure due to
normal wear or tool abuse. for further detail of warranty
coverage and warranty repair information, visit www.dewalt.
com or call 1-800-4-D
warranty does not apply to accessories or damage caused
where repairs have been made or attempted by others. This
warranty gives you specific legal rights any you may have
other rights which vary in certain states or provinces.
wALT,
In addition to the warranty, D
D
wALT will maintain the tool and replace worn parts caused by
E
normal use, for free, any time during the first year after purchase.
90 DAY MONEY BACK GUARANTEE
If you are not completely satisfied with the performance of
your D
wALT Powder Actuated Tool for any reason, you can
E
return it within 90 days from the date of purchase with a
receipt for a full refund – no questions asked.
R2200
FREE WARNING LABEL REPLACEMENT:
If your warning labels become illegible or are missing call
1-800-4-D
wALT (1-800-433-9258) for a free replacement.
E
Introduction
Thank you for purchasing the D
powder actuated tool. This tool will provide you with excellent
performance provided the steps for proper operation and
maintenance are followed. Powder actuated fastening
systems can provide a cost effective method of attaching
fixtures for light duty, static load conditions. The systems
provided by D
wALT consist of specially designed fasteners,
E
installation tools, and powder loads which are designed to
function in combination to provide optimum performance.
while powder actuated tools can provide one of the fastest
and economical means of fastening, they can also be
dangerous if they are not operated properly.
Prior to operating the T1000 tool, you must be properly
trained in the operation and maintenance of this tool and be
issued a D
wALT qualified Operator Card. when using the
E
tool, you must have this card in your possession. As part
of the training process, you should read and understand
1
Cat. No. DDF211001P
wALT (1-800-433-9258). This
E
wALT tools are covered by our:
E
1 YEAR FREE SERVICE
wALT T1000 low velocity
E
