DMX PROTOCOL
DIMMER
CH1
STROBE
CH2
PAN
CH3
PAN Précis
CH4
TILT
CH5
TILT Précis
CH6
PAN-TILT vitesse
CH7
ROUE COULEUR
CH8
ROUE GOBOS FIXE
CH9
0-255
Dimmer 0-100%
0-3
Not used
Strobe from
4-251
Slow to Fast
252-255
Not used
0-255
PAN
0-255
PAN Fine
0-255
TILT
0-255
TILT Fine
0-255
PAN-TILT Speed
0-4
White
5-9
Color 1
10-14
Color 2
15-19
Color 3
20-24
Color 4
25-29
Color 5
30-34
Color 6
35-39
Color 7
40-44
White + Color 1
45-49
Color 1 + Color 2
50-54
Color 2 + Color 3
55-59
Color 3 + Color 4
60-64
Color 4 + Color 5
65-69
Color 5 + Color 6
70-74
Color 6 + Color 7
75-79
Color 7 + White
Rotate from
80-255
Slow to Fast
0-9
White
10-19
Gobo 1
20-29
Gobo 2
30-39
Gobo 3
40-49
Gobo 4
50-59
Gobo 5
60-69
Gobo 6
70-79
Gobo 7
ROTATION
80-129
Counterclockwise
Slow to Fast
130-134
White
ROTATION clockwise
135-220
Slow to Fast
GOBO 1 SHAKE
221-225
Slow to Fast
GOBO 2 SHAKE
226-230
Slow to Fast
GOBO 3 SHAKE
231 - 235
Slow to Fast
GOBO 4 SHAKE
236-240
Slow to Fast
GOBO 5 SHAKE
241- 245
Slow to Fast
ROUE GOBOS FIXE
CH9
ROUE GOBOS
ROTATIFS
CH10
ROTATION GOBOS
CH11
PRISME
FOCUS
RESET
P.21
GOBO 6 SHAKE
246-250
Slow to Fast
GOBO 7 SHAKE
251-255
Slow to Fast
0-9
White
10-19
Gobo 1
20-29
Gobo 2
30-39
Gobo 3
40-49
Gobo 4
50-59
Gobo 5
60-69
Gobo 6
ROTATION
70-129
Counterclockwise
Slow to Fast
130-134
White
ROTATION
135-225
clockwise
Slow to Fast
GOBO 1 SHAKE
226-230
Slow to Fast
GOBO 2 SHAKE
231-235
Slow to Fast
GOBO 3 SHAKE
236-260
Slow to Fast
GOBO 4 SHAKE
241-245
Slow to Fast
GOBO 5 SHAKE
246-250
Slow to Fast
GOBO 6 SHAKE
251-255
Slow to Fast
0-63
POSITION
ROTATION
64-127
clockwise
Slow to Fast
ROTATION
128-190
clockwise
Fast to Slow
191-192
Stop Rotation
ROTATION
193-255
Counterclockwise
Slow to Fast
0-9
No Prism
10-14
Prism Inserted
Rotation Prisme
15-255
Lent > Rapide
0-255
Focus 0-100%
0-249
Complete RESET
250-255
Not used
