MENU AND CONTROLS
Manu
CONTRÔLE MANUEL
Manu
1. Dimmer
2. Shutter/Strobe
3. Pan
4. Pan Fine
5. Tilt
6. Tilt Fine
Advan
ADVANCED
Password is "Up Up Up Down Down Down", then press the OK key enter into the Advanced Interface.
SENSOR MONITOR
RESET CALIBRATION
ZERO POINT CORRECTION
This interface is used to control the current and automatically enters the master
state (does not receive the DMX signal and sends a DMX signal to the slave).
OPTION
1. Dimmer
2.Shutter/Strobe
3. Pan
4. Pan Fine
5. Tilt
6. Tilt Fine
7. Pan/Tilt Speed
8. Color
9. Fixed Gobo Wheel
10. Rotation Gobo Wheel
11. Gobo Rotate
12. Prism
13. Focus
14. Reset
Hall 1-6 State
Hall X-Y
Pan Tilt Codewheel state
Pan codewheel Step
Tilt codewheel Step
Pan Calibration
Tilt Calibration
Color Calibration
Gobo Calibration
Focus Calibration
Rt Gobo Calibration
ON
DESCRITPION
0-255
0-255
0-255
0-255
0-255
Orange indicates selected,
0-255
Press "OK" key enter into Edit status,
0-255
then press "UP" "DOWN" to select,
0-255
press "OK" save and Exit edit status.
0-255
0-255
0-255
0-255
0-255
0-255
Press "OK" to see the confirmation
+
After entering the sub interface, you can adjust the motor
such as X axis and Y axis. Reset position to compensate for
errors in hardware installation.
Adjustment range 128~+127, +0 means no adjustment.
P.18
