PRODUCT PRESENTATION
1
2
10
9
8
FUNCTION
1
LED error indicator
2
LED DMX indicator
3
LCD display
4
Keyboard
5
Mains switch
6
Protection fuse
7
Power OUT connector
8
Power IN connector
9
DMX OUTXLR connector
DMX IN XLR connector
10
INTERFACE DESCRIPTION
Adress DMX
Settings Menu
Manual mode
Use buttons "UP" and "DOWN" to navigate in main menu. Press "ENTER" to confirm your selection.
MS100
Led Moving Beam
DMX
ERROR
DESCRITPION
Flashes to indicate that there is an error message
Lights ON when the DMX signal is received
Menu and function display
For menu and sub-menu navigation
Power switch ON/OFF
Electric fuse protection
To connect more fixtures . Load max. 960W
Power input. Use incuded power lead
DMX signal output
DMX signal input
001
Set Manu
Sys
EN
DMX
RDM
Advan
P.17
3
4
5
6
7
Reverse display
Select language
Advanced system menu
System Menu
