3. INSTALLATION INSTRUCTIONS
LOCATION OF THE ELECTRICAL WIRING
Location of the electrical wiring must be within the range given below.
ATTENTION:
Do not use extension cables or two-pin adaptors and do not remove the ground terminal of the
grounding cable.
ATTENTION:
A qualified electrician must ensure that the poles of the socket are connected correctly. Verify that
the grounding of the socket is correct.
Configuration
"A" Dimension
13" (330mm)
54
18+24
18+30
19" (482mm)
24+24
24+30
13" (330mm)
19" (482mm)
30+30
19" (482mm)
