Connect to Drain
1
Connect drain hose
Green clamp
Black drain hose
connector
Stop
Place towel under drain hose to catch any water in drain hose.
Place the small green drain hose clamp onto the small end of
the drain hose. Push the new drain hose into the black drain
hose connector up to the drain hose stop.
2
Slide clamp onto connector
Green clamp
Black drain hose
connector
Using pliers, squeeze open the small green drain hose clamp
and slide onto connector between stops.
16
Drain hose
Drain hose stop
Stop
Drain hose
Drain hose stop
Stop
Stop
3
Hose clamp final position
Green clamp
Black drain hose
connector
Once connected, remove towel.
If needed, see website for animated representation of this step.
Visit www.whirlpool.com/drain under FAQ tab.
Make Direct Wire Electrical
Connection
NOTE: If the power supply cord was connected earlier
proceed to "Secure Dishwasher in Cabinet Opening" section.
Option B, Direct Wire:
Direct Wire—Route cable
1
into terminal box
Route cable so that it does not touch dishwasher motor or
lower part of dishwasher tub. Pull cable through cable clamp in
terminal box.
Select UL listed or CSA approved twist-on wire connectors
(not included) rated to connect your household wiring to 16-gauge
dishwasher wiring.
Drain hose
Drain hose stop
Stop
Stop
