Emerson Appleton Areamaster Instructions D'installation page 19

imens es
(4) YOKE BOLTS
COUNDUIT ENTRY
Imagem 1: umi ria E
(3) MOUNTING HOLES 0.56" DIA
3/4-14 NPT
See figure A
(1) 3/4-14 NPT
3/4-14 NPT THREADS FOR HOOK OR CONDUIT
MOUNTING (NO ACCESS TO FIXTURE INTERIOR)
SET-SCREW
FIGURE A
reamaster E
YOKE
6.0" TURNING RADIUS 180° ROTATION
(4) 1/4-20 UNC-2B THREADS
See figure B
(2) 3/4" CLOSE-UP PLUGS
FIGURE B
1/4-20 UNC-2B THREADS FOR EYE BOLT MOUNTING
650525-000 Rev. G 04/02/19 • Page 19 of 29
