Fitting The Handle To The Power Source - Fronius Transpocket 4000 Cel Instructions De Service

Straighten the locking devices and secure them
Fitting the hand-
le to the power
source
Allow the handle plates to engage
Handle plates and handle tube
IMPORTANT! When fitting the two handle plates (1) together, make sure that
the locking devices (2) on the underside of the handle plates (1) are fully enga-
ged.
(4)
(3) (3)
(1) (2) (2) (1)
(2)
(3) (1)
Straighten the locking devices by
7
(4)
moving the outer threaded bolts
(4) as far as they will go
Tighten the six wing nuts (3)
8
Carefully place the trolley with
9
power source on its wheels
(3)
(2)
(1)
87
