Preparation
NOTE: To avoid damage to your hood, prevent debris from entering the vent opening.
1. Determine and mark the center line o n the wall where the range hood will be installed.
Make sure there is proper cl earanc e within the c eiling or w all for exhaust vent.
2. Due to the w eight and size of this unit, please make sure that the supp ort system or
framew ork being used is stable and sec ure in the wall or c eiling.
3. Put a thick, pro tective covering o ver c ounter top, c ook top or range to protect from
damage or dirt. Remove any haz ardo us obj ec ts around the area when installing.
4. Mark the lo cations of the support mounting brac ket holes, d uc ting cutout (if used ) and
power supply cable cutout on the wall or ceiling behind the chimney covers. Use drill
and saber saw or keyhole saw to cut opening for power supply cable and ducting (see
Venting Requirement and Electrical Requirements, pages 5-8).
5. If venting to the outside install vent system (see Venting Methods, page 7). Use caulking
to seal the exterior wall or roof openings.
6. Disconnect main electrical supply, prepare and run electrical wiring through ceiling or
wall. Install a power outlet within reaching distance of the range hood assembly. DO
NOT restore power until installation is completed.
7. Disconnect the power cord and remove the stainless steel baffle filters as shown on
Figure 1.
8. Set aside the stainless steel baffle filters until the range hood is installed.
9. Assemble the duct adapter onto the range hood body. Place the duct adapter gasket
into the hollow perimeter of the rectangular side of the duct adapter; place the
rectangular side of the duct adapter over the range hood duct, aligning screw holes;
fasten the duct adapter onto the range hood body using the supplied hardware: "D"
screws.
Baffle Filter Installation
Figure 1
Severe Injury
Rotating fan can cause severe
injury. Stay clear of fan when
power is present.
Pg 9
