Error Prompts and Solutions
EN
Troubleshooting
Possible Cause
Code
E1-E7
Error
H1-H6
H7
Battery overheating
E8
Blocked tube
Specifications
Model
HHR20A
Rated Voltage
21.6 V
Clean Water
900 mL/30.44 oz
Tank Capacity
Model
100-240 V
Rated Input
/60 Hz 0.8 A Max
Power Adapter (alternative)
Model
100-240 V
Rated Input
/60 Hz 1.2 A
13
13
Solution
Restart the appliance for
troubleshooting. If the problem persists,
please contact customer service
Wait until the battery's temperature
returns normal
Refer to the Care & Maintenance section
to clean the tube.
Floor Washer
Charging Time
approx. 4.5 hours
35 min（Quite
Run Time
Mode）
Rated Power
300 W
Used Water Tank
700 mL/23.67 oz
Capacity
Power Adapter
YLS0251B-T260090
50
Rated Output
26.0 V
KL-WA260090-A3
50
Rated Output
26.0 V
Battery Disposal and Removal
The built-in lithium-ion battery contains substances that are hazardous to the environment.
Before disposing of the battery, make sure the battery is removed by qualified technicians and
discarded at an appropriate recycling facility.
– the battery must be removed from the appliance before it is scrapped;
– the appliance must be disconnected from the supply mains when removing the battery;
– the battery is to be disposed of safely.
Removal Guide
1. Remove the screw plug at the top of the back of the appliance and remove the screw by a
screwdriver.
2. Use a proper tool to remove the display assembly and disconnect the cables.
3. Use a screwdriver to remove all the fixing screws from the body.
4. Remove the screws on the battery pack assembly and then remove the battery cover.
5. Disconnect the battery pack's connector cables and remove the battery from the battery
pack assembly.
CAUTION:
Before removing the battery, disconnect the power and run out the battery as much as
•
possible.
Unneeded batteries should be discarded at an appropriate recycling facility.
•
Do not expose to high temperature environment to avoid risks of explosion.
•
Under abusive conditions, liquid may be ejected from the battery. If contact occurs, flush
•
with water and seek medical help.
0.9 A
0.9 A
EN
14
14
