WARNING!
The use of a swimming pool implies compliance with the safety instructions described in the operating and
maintenance guide.
In order to prevent drowning or other serious injuries, pay particular attention to the possibility of unexpected access to the
swimming pool by children under 5 years by securing the access to it and keeping them under constant adult supervision
while in the pool.
Please read carefully and keep for future reference.
SETUP INSTRUCTIONS
Overview
Choosing the Correct Location:
The location chosen where the pool will be installed
must respect the following conditions:
- Because of the combined weight of the water inside
the pool and the users, it is extremely important that
the surface chosen is capable of uniformly supporting
the total weight for the entire time the pool is installed.
When choosing the surface, take into consideration
that water may come out of the pool when in use or
when it rains. If the water softens the surface, it may
lose its capability to support the pool weight.
- Check the position of the vertical legs and/or the
U-supports regularly. They must always be level with the bottom of the pool. If the vertical leg or the U-support starts to sink
into the ground, drain the pool water immediately to avoid the pool collapsing due to the uneven load on the frame
structure. Change the location of the pool or modify the surface material.
- The surface must be flat and smooth. If the surface is inclined or uneven, it can create an unbalanced load on the structure
of the pool. This can damage the welding points of the liner and bend the frame. In the worst cases, the pool can collapse,
causing serious personal injury and/or damage to personal property.
- We recommend positioning the pool away from any objects children could use to climb into the pool.
- Position the pool near an adequate drainage system to deal with overflow or to empty the pool. Ensure the pool side with
the water inlet A and outlet B is facing in the direction of the power source, where the filtration system will be connected.
- The selected surface must be clear of any type of object. Due to the weight of the water, any object under the pool could
damage or perforate the bottom of the pool.
- The selected surface must be clear of aggressive plants and weed species. Types of strong vegetation could grow through the
liner and create water leakage. Grass or other vegetation that may cause odor or slime to develop must be eliminated from
the chosen location.
- The selected location must not have overhead power lines or trees. Be sure the location does not contain underground
utility pipes, lines or cables of any kind.
- The selected position must be far from house entrance. Do not position any equipment or other furniture around the pool.
The water that comes out of the pool during use or due to product malfunctions can damage furniture inside the house or
surrounding the pool.
- The selected surface must be flat and without holes that can damage the material of the liner.
Suggested surfaces: grass, ground, concrete and all other surfaces that respect the above set-up conditions.
Surfaces to avoid: mud, sand, gravel, deck, balcony, driveway, platform, soft/loose soil or other surface that does not meet
the above set-up conditions.
Follow the important instructions above to choose the correct surface and location to set up your pool. If parts become
damaged because the set-up surface and location does not adhere to these instructions, it will not be considered a manufacturer
defect and will void the warranty and any service claims.
If the selected surface is too soft to hold the frame, install wood or metal plates with a thickness of no bigger than 0.02 m under
the legs. The plates must not touch the liner or have a sharp area, as this can cause damage and will not be covered under the
manufacturer's warranty.
Additional Guidelines:
Check with your local city council for bylaws relating to fencing, barriers, lighting and safety requirements, and ensure you
comply with all laws.
If a pump and/or ladder is included in the set, refer to the pump's and/or ladder's manual for safety instructions and
installation. The ladder must match the pool size.
If you must change locations during set-up, lift the liner to move it; do not drag it on the ground. The friction between the PVC
material and the ground can damage the pool liner.
Parts & Tools Needed
Compare the parts in your box to the parts listed in this manual.
model that you had intended to purchase.
Assembly Instructions
For installation instructions, follow the illustrations inside the manual.
not reflect actual product. Not to scale.
Max. 0.02 m
Verify that the equipment components represent the
Drawings are for illustration purposes only. May
