A recorder can be connected to the red (+) and black (-) terminals. Use only labo-
ratory recorders with a high input impedance!
A standard RS232 output terminal (DP9) is provided for interfacing the instru-
ment with a printer or computer. Data is sent in the ASCII code at a BAUD rate
of 150...4800 bps (8 bit, no parity, 1 stopbit).
Serial port pinout specifications:
pin 1 : connected to pin 4 and pin 6
pin 2 : TxD, transmit data
pin 3 : RxD, receive data
pin 4 : connected to pin 1 and pin 6
pin 5 : Gnd, signal ground
pin 6 : connected to pin 1 and pin 4
pin 7 : connected to pin 8
pin 8 : connected to pin 7
pin 9 : not connected
1. Select [MAIN MENU] by pressing MODE.
2. Select [SET-UP], [SYSTEM] and press CAL.
3. Follow the in struc tions on the screen to adjust language, con trast and automa-
tic power-off timer.
1. Select [MAIN MENU] by pressing MODE.
2. Select [SET-UP], [DATE/TIME] and press CAL.
3. Adjust the date (respectively year, month and day) by pressing CAL each
time.
4. Adjust the time (respectively hour, minutes and seconds) by pressing CAL each
time.
1. Select [MAIN MENU] by pressing MODE.
2. Select [SET-UP], [RECORDER] and press CAL.
3. Select the desired range and press CAL.
4. Select the desired minimum level corresponding to a 0 V recorder output and
press CAL.
5. Select the desired maximum level corresponding to a 2 V recorder output and
press CAL.
(P902, P903)
1. Select [MAIN MENU] by pressing MODE.
2. Select [SET-UP], [PASSWORD] and press CAL.
3. A private code can be pro grammed to avoid unde sired access to the instru-
ment. Enter your secret sequence of 5 keys and press CAL.
P901 • P902 • P903 P901 • P902 • P903

Recorder output

Digital output

System

Date and Time
Recorder Recorder
Password Password
