MEANING OF LED
LED
SET AMBIANCE
SET POWER
CHRONO
ALARM
SPARK PLUG
SCREW FEEDER ON
EXCHANGER-PUMP
ON\OFF
DISPLAY
DISPLAY FUNCTION
DISPLAY Power status
Parameter name
OPERATING MODE
The normal operation of the electronic board regularly installed in a stove is described
•
below with reference to the functions available to the user. The indications below refer to
the electronic board equipped with a chrono thermostat option. In the following
paragraphs, on the other hand, the technical programming method is analysed.
Before turning on the stove the display looks like in figure 3.
•
IGNITION OF THE STOVE
•
To turn on the stove act on the P 3 button for a few seconds. The ignition is indicated in
the display as per fig. 4 and the flashing of the LED ON/OFF
In these conditions the stove is placed in the state of pre-ventilation, the glow plug and
•
the fume extraction fan are lit.
Meaning when turned on
Environment set programming
Power set programming
Chrono enabled
Stove on alarm
Glow plug ignition
Moving auger
Heat exchanger\ pump on
Job Status
CONDITIONS
VIEW
OFF OFF+TEMPERATURE ROOM
Acc. ON + TEMPERATURE ROOM
Loading PELLET LOADING
Work TEMPERATURE ROOM + POWER+ WORK+HOUR
Programming SELECTED PARAMETER
49/148
IT IT IT IT- - - - EN EN- - - - FR FR- - - - ES ES mod. ERICA PLUS
EN EN FR FR ES ES
Figura 3
Figura 4
