(STEP 1 cont.)
Once the outside antenna is assembled
at the correct height, apply the thread
locker precisely to thread points only, not
to the plastic body of the antenna. Screw
mast onto the antenna.
Connect the 7.6 m cable to the outside
antenna cable. Optional heat shrink tube
can be applied to the connection.
connect
cables
4.3 m cable
Outside
Antenna
add Thread
Locker
mast
Outside
Antenna
cable
Heat Shrink
(optional)
mast
add Thread
Locker
Side Exit
Adapter
add Thread
Locker
6
6
