SKF FlowMaster II Instructions D'utilisation Et De Maintenance page 8

Fig. 2
Dimensions de modèle 85722-AU
18.9 in
∅ 15.1 in (384 mm)
(479 mm)
∅ 13.8 in (352 mm)
18.2 in
(462 mm)
∅ 0.50 in (13 mm)
40°
20°
A-A
31.6 in
(802 mm)
A A
8
