SICK LMS4400 Notice D'instruction page 103

Table 130 : Telegram structure: sWN LFPfrontendEdgefilter
Telegram structure: sWN LFPfrontendEdgefilter
(User level 'Authorized client' required)
Telegram Description
part
Command Write
type
Command Set Front End Edge fil‐
ter
Status Activate / deactivate
code
Reserved -
Table 131 : Example: sWN LFPfrontendEdgefilter
<STX>sWN{SPC}LFPfrontendEdgefilter{SPC}0{SPC}1<ETX>
<STX>sWN LFPparticle 0 1<ETX>
CoLa A
sWN LFPparticle 0 1
02 73 57 4E 20 4C 46 50 66 72 6F 6E 74 65 6E 64 45 64 67 65 66 69 6C 74 65 72
02 02 02 02 00 00 00 1C
00 01 1C
CoLa B
73 57 4E 20 4C 46 50 66 72 6F 6E 74 65 6E 64 45 64 67 65 66 69 6C 74 65 72 20 01 01
Table 132 : Telegram structure: sWA LFPfrontendEdgefilter
Telegram structure: sWA LFPfrontendEdgefilter
Telegram Description
part
Command Answer
type
Command Set Front End Edge fil‐
ter
Table 133 : Example: sWA LFPfrontendEdgefilter
<STX>sWA{SPC}LFPfrontendEdgefilter<ETX>
CoLa A
02 73 57 41 20 4C 46 50 66 72 6F 6E 74 65 6E 64 45 64 67 65 66 69 6C 74 65 72
02 02 02 02 00 00 00 1A
CoLa B
12
12.3.1.4.5.4
Activate the Edge filter to eliminate wrong measurement points at object edges.
8027169/1MNR/2024-10-25 | SICK
Subject to change without notice
Variable Length
String 3
String 21
Bool_1 1
Enum_8 1
73 57 4E 20 4C 46 50 66 72 6F 6E 74 65 6E 64 45 64 67 65 66 69 6C 74 65 72
Variable Length
String 3
String 21
73 57 41 20 4C 46 50 66 72 6F 6E 74 65 6E 64 45 64 67 65 66 69 6C 74 65 72
Activate Edge filter [sWN LFPedgefilter]
Additional details
Activate:
Deactivate:
Always:
Sensor
N O T I C E D ' I N S T R U C T I O N | LMS4400/LMS4500
ANNEXE
Values CoLa A Values CoLa B
(ASCII) (Binary)
sWN 73 57 4E
LFPfronten‐ 4C 46 50 66
dEdgefilter 72 6F 6E 74 65
6E 64 45 64 67
65 66 69 6C
74 65 72
0 00
1 01
1 01
20 30 20 31 03
20
Values CoLa A Values CoLa B
(ASCII) (Binary)
sWA 73 57 41
LFPfronten‐ 4C 46 50 66
dEdgefilter 72 6F 6E 74 65
6E 64 45 64 67
65 66 69 6C
74 65 72
03
20
12
