RC Si M30
Montage- und Anschlussanleitung / Sicherheitssensor
Mounting and wiring instructions / Safety sensor
Instructions de montage et de câblage / Capteur de sécurité
Istruzioni di montaggio e collegamento / Sensore di sicurezza
Instruções de montagem e instalação / Sensor de segurança
Deutsch (Originalbetriebsanleitung)
Reinigung
- Bei feuchter Reinigung: Wasser oder milde, nicht-scheuernde,
nicht-kratzende Reinigungsmittel verwenden.
- Keine aggressiven Reinigungs- oder Lösungsmittel verwenden.

Entsorgung

- Nationale, lokale und gesetzliche Bestimmungen zur
Entsorgung beachten.
- Materialien getrennt dem Recycling zuführen.
English
Use of the mounting and wiring instructions
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer.
In case of doubt, the German language version of these instructions
shall prevail.
Scope of delivery
Device, mounting and wiring instructions, packaging.
Intended use
The device is used in safety circuits to monitor the position of moving
safety guards to EN ISO 14119 (EN 1088) type 4 and EN 60947-5-3. The
EN 60947-5-3 standard is only met if the entire system consisting of
the safety sensor, the actuator and a safety module.
Mounting and wiring
Mount the sensor and the actuator on an even surface and opposite
each other according to the marks on the sensor and actuator. Due to
the danger of manipulation: prevent accessibility to actuators and
spare actuators. Ensure that the device cannot be moved from its posi-
tion. Ensure this in case of failure, too. In addition, the actuator must
be positioned and/or protected in such a way that damage by foreseea-
ble external forces is prevented. When mounting actuator and sensor
please observe the requirements of EN ISO 14119, especially para-
graph 7, »Construction to reduce manipulation of interlocking devic-
es«! For protection against manipulation use one-way safety screws,
Torx with pin, riveting, etc. Sensor and actuator should not be fixed on
ferromagnetic material, this leads to strong changes of the switching
distances. Do not install the sensor and the actuator in strong magnet-
ic fields. Keep away ferromagnetic cuttings. Do not expose the device
to extreme vibrations and shocks. Protected wiring by cable conduit,
armoured conduit or similar is required for the variants RC Si M30 2Ö
in order to avoid faults by short-circuiting. With the variants RC Si M30
1Ö/1S, monitoring of the antivalence is required. A mounting distance
of min. 50 mm between two systems must be observed. The device
must be mounted in such a way that unintentional contact is not possi-
ble. Depending on the electrical load, the sensor must be protected
from voltage and current peaks by suitable protection circuits. It is
required to distinguish between ohmic, inductive and capacitive load.
Observe the instructions in the standards EN ISO 12100 and
EN ISO 14120.
N.B.
The specified switching distances refer to face-to-face mounted sen-
sors and actuators. Different arrangements are possible, may lead to
different switching distances, however. The maximum possible offset
between actuator and sensor can be found in the diagram »Axial mis-
alignment«. It must be observed that protective guards like doors,
grids, etc. change their position / direction in due time because of me-
chanical wear. The switch-off distance (s ar ) between sensor and actu-
ator must be observed (opening of the safety guard). After wiring, per-
form a functional test by opening and closing the protective guard.
Closing of the protective guard must not lead to an automatic start of a
dangerous machine function. This may only be initiated by a start com-
mand. Verify the correct function by observing the connected safety
module. The connected safety module also defines the maximum
switching frequency of the device. Do not use the sensor as mechani-
cal endstop. Any mounting position is possible. Reconstruction and al-
terations to the device are not allowed. For the integration of the de-
vice in the entire system: strictly observe and respect the control cate-
gory determined in the risk assessment. Therefore, a validation ac-
cording to EN ISO 13849-2 or EN 62061 is necessary. Furthermore, the
Performance Level according to EN ISO 13849-1 and SIL CL Level ac-
cording to EN 62061 can be lower than the single level because of the
combination of several safety components and other safety-related
devices, e.g. by serial connection of sensors. It is the responsibility of
the manufacturer of a plant or machine to guarantee the correct gen-
eral function. Subject to technical modifications.
Maintenance
With careful mounting as described above, only minor maintenance is
necessary. We recommend a routine maintenance as follows:
1. Check switching function.
2. Check for tight installation of the sensor and coded actuator.
3. Check for alignment of sensor and actuator.
4. Remove dirt and metal shavings.
5. Check enclosure for damage.
Behaviour in case of failure
No enabling signal indicated with closed protective guard. This can be
triggered by the following:
- alignment of sensor and actuator not correct
- safe switch-off distance not reached
- interference by strong external magnetic fields
