StandardSpray
Align the feed tube
If the feed tube is positioned correctly, the container contents can be sprayed without
almost any residue.
When working on lying objects: Turn the feed tube forwards. (Fig. 4 A)
When working on lying objects: Turn the feed tube forwards. (Fig. 4 B)
Cleaning
1. Unscrew the container. Empty the remaining coating material into the original container.
2. Unscrew feed tube with container seal. (Fig. 5)
3. Clean feed tube and suction nozzle in spray attachment with cleaning brush.
4. Clean the ventilating bore. (Fig. 5, 1)
CAUTION! Never clean seals, diaphragm and nozzle or air holes of the
spray gun with metal objects. The ventilation hose and diaphragm are
only solvent-resistant to a limited extent. Do not immerse in solvent,
only wipe.
5. Move the air cap (Fig. 6, 1) to the vertical position for easier removal and lift it off.
6. Unscrew the union nut (fig. 6, 2).
7. Clean the air cap (fig. 6, 1) and nozzle (3) with a brush and solvent or water.
8. Take special care when cleaning the interstices on the needle (Fig. 6, 4)
9. Clean the outside of the spray gun and container with a cloth soaked in solvent or
water.
10. Push nozzle seal onto the needle so that the groove (slot) points away from the spray
attachment. (Fig. 7)
11. Screw the union nut (Fig. 8, 2) onto the gun and tighten it.
12. Engage the air cap (Fig. 9, 1) with the union nut. Check if the air cap has properly locked
into place on both sides.
13. Place the container seal from below on the feed tube and slide it over the collar, while
turning the container seal slightly.
14. Screw the feed tube with the container seal into the body of the gun.
Maintenance
If paint has entered the ventilation hose, proceed as follows:
1. Pull the ventilating hose (Fig. 10, 1) at the top from the gun body. Screw off the valve
cover (2). Remove the diaphragm (3). Clean all the parts carefully.
2. Place the diaphragm in the valve cover with the pin facing forward (Also see the marking
on the gun body).
3. Turn the body of the gun upside down and screw on the valve cover from underneath.
4. Place the ventilating hose on the valve cover and on the nipple at the gun body.
