GB
MODELS
FM400OC2
Plug-in receiver with "open collector" outputs for FM400 series remote controls
NOIREOC2
Plug-in receiver with "open collector" outputs for NOIRE series remote controls
EDGEOC2
Plug-in receiver with "open collector" outputs for EDGE series remote controls
Also compatible with transmitters in the previous series TANGO (NO Rolling-Code,
NO TangoSW)
TANGOOC2SW
Plug-in receiver with "open collector" outputs for TANGO SW series remote controls
SPECIFICATIONS
The FM400, NOIRE, EDGE and TANGOSW series are self-learning receivers with
"open collector" outputs. These 3 series (no TANGOSW) feature a digital coding
system with over a million different combinations. The transmitters do not require any
programming since the code, different for each transmitter, is set at the factory during
the testing operations. The FM400 / NOIRE series is an advanced version of
traditional remote controls; its "Rolling-Code" variable code system provides
enhanced security and inviolability. Moreover, the FM400 series operates with
frequency modulation (FSK).
RECEIVER TECHNICAL SPECIFICATIONS
Power supply
Consumption when idle
Operating temperature
Memorizable codes
Memorizable codes
Memorizable codes
Memorizable codes
22
u.m.
FM400OC2 NOIREOC2 EDGEOC2
Vdc 5
mA 12
°C -20 +60
24LC04 -
24LC16 -
24LC32 500
24LC64 1012
5 5
12 12
-20+60 -20+60
163
163 / 70 (R.C.)
675
675 / 289 (R.C.)
- -
- -
TANGO
OC2 SW
5
12
-20+60
244
1012
-
-
