6
Remote controller button functions
(4)
button
RETURN
(3)
button
MENU
(5)
SELECT/HOLD
button
ON/OFF
(1)
button
Use to turn ON/OFF the indoor unit.
(2) Function buttons
Use to select the operation mode or to set the
temperature and fan speed on the Main display.
Use to select items on other screens.
(3)
MENU
button
Use to bring up the Main menu.
(4)
button
RETURN
Use to return to the previous screen.
(5)
SELECT/HOLD
button
Use to jump to the setting screen or to save the
settings.
When the Main display is displayed, pressing
this button will enable/disable the HOLD
function.
(6) Operation indicator
Stays lit during normal operation. Blinks during
startup and when an error occurs.
(7) Backlit LCD
Dot display. When the backlight is off, pressing
any button turns the backlight on and it will stay
lit for a certain period of time depending on the
screen. Performing any button operation keeps
the backlight on.
Note: When the backlight is off, pressing any
button turns the backlight on and does not
perform its function. (except for the
button)
ON/OFF
(7) Backlit LCD
(2) Function buttons
F1
,
F2
(6) Operation indicator
(1)
ON/OFF
MENU
Pressing the
menu as shown below.
Operation menu *1
Timer menu *1
Energy saving menu *1
Initial setting menu *2*3
Maintenance menu *1
Service menu *2*3
*1 Refer to the Instructions Book for details.
*2 Explained in this manual.
*3 If no buttons are pressed for 10 minutes on the
initial setting screens, or 2 hours on the service
screens (10 minutes on some screens), the
screen will automatically return to the Main
display. Any settings that have not been saved
will be lost.
The available items on the menu depend on the
connected indoor unit model. For items not
described in the manuals that are enclosed with
the MA Remote Controller, refer to the manuals
that came with the air conditioning units.
– 14 –
,
F3
, and
F4
from the left
button
button will bring up the Main
